Sharp AR-5726 - 操作部 (Operation Panel Unit)

– 5 –
Update : 2009/11/16
3
操作部 (Operation panel unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 PSH EZ0 646QSP Z AE DJ C
PWB protect sheet 基板保護ｼｰﾄ
2 XEB S73 0P0800 0 AC DD C
Screw(3×8) ﾋﾞｽ
3 DHA I-0 503QSP Z AE DS C
KEY PWB harness KEY 基板ﾊｰﾈｽ
4
CPWBX0 211 QSF2 BR LX E
OPU PWB (North America,Philippines,Thailand,
Indonesia,India,Special country,Malaysia,
Singapore,Argentina) OPU 基板
CPWBX0 211 QSF4 BR LX E OPU PWB (Europe,U.kingdom) OPU 基板
CPWBX0 211 QSF5 BR LX E
OPU PWB (Germany,Switzerland,East Europe) OPU 基板
CPWBX0 211 QSF7 BR LX E
OPU PWB (Algeria,Iran,Egypt,Syria,Tunisa,Nigeria,
West Africa,Morocco,Jordan,Lebanon,UAE,
Yemen,Oman,Qutar,Kuwait,Bahrain,Saudi Arabia) OPU 基板
CPWBX0 211 QSF3 BR LX E
OPU PWB (Japan) OPU 基板
5 MSP RP3 009FCZ Z AD DJ C
LCD earth plate LCD 用ｱｰｽ板
6 LHL DZ0 119QSZ Z AK EB C
LCD holder B LCD ﾎﾙﾀﾞｰ B
7 VVL 81H B1T03- A BV RB B
LCD module LCD ﾓｼﾞｭｰﾙ
8 LHL DZ0 118QSZ Z AL EB C
LCD holder LCD ﾎﾙﾀﾞｰ
9 PSH EZ5 764FCZ Z AC DJ C
Touch panel sheet ﾀﾂﾁﾊﾟﾈﾙｼｰﾄ
10 HPN LH0264 FCZZ BF GN B
Touch panel 8.1 ﾀｯﾁﾊﾟﾈﾙ 8.1
11
CPNLC0 072 QS05 AX FG C
Operation panel B EX (Except Germany,Switzerland,
East Europe,Japan) 操作ﾊﾟﾈﾙ B EX
CPNLC0 072 QS03 -AXFG C
Operation panel AS [Missing parts code]
(Germany,Switzerland,East Europe) 操作ﾊﾟﾈﾙ AS
1st lot
CPNLC0 072 QS04 AX FG C
Operation panel B J (Japan) 操作ﾊﾟﾈﾙ B J
14 PLN S-0016 QSZZ AD DJ B
FAX Lens (Japan) FAX ﾚﾝｽﾞ
15
CPNLC0 070 QS02 AR EQ C
Operation panel 8.1 EX (Except Japan) 操作ﾊﾟﾈﾙ
A8.1EX
CPNLC0 070 QS01 AT EZ C
Operation panel 8.1 J (Japan) 操作ﾊﾟﾈﾙ A8.1J
18 JBT N-0071 QSA1 AR EQ C
Mode key ﾓｰﾄﾞｷｰ
19 CBT N-0290 FC01 AK DX C
Ten key ﾃﾝｷｰ
20 CBT N-0292 FC03 AR EQ C
Interrupt key 割り込みｷｰ
21 PFI LW0319 FCZZ AK EB C
Copy key ring ｺﾋﾟｰｷｰﾘﾝｸﾞ
22 PLN S-0105 FCZZ AC DJ B
Power supply key lens 電源ｷｰ用ﾚﾝｽﾞ
23
CBTN-0 291 FC02 AG DX C
CA key EX (Except Japan) CA ｷｰ EX
CBTN-0 291 FC01 AG DX C
CA key J (Japan) CA ｷｰ J
24 JBT N-0284 FCAZ AR EQ C
Copy key ｺﾋﾟｰｷｰ
25
CPWBF0 234 QSE2 AX FG E
Key PWB (MX-M Series except Japan) KEY 基板
CPWBF0 234 QSE1 AZ FX E
Key PWB (Japan) KEY 基板
CPWBF0 234 QSE3 AY FQ E
Key PWB (AR-57 Series) KEY 基板
26 LDA IU0037 QSZZ AS EZ C
Operation base plate A 操作台板 A
27 QCN W-0249 FCPZ AZ FQ C
LCD-FFC P2 LCD-FFC P2
28
LDAIU0 038 QSZZ AQ EQ C
Operation base plate B 操作台板 B
LDAIU0 038 QSZ1 1AQEQ C
Operation base plate B 操作台板 B
09/08 mid
29 XEB S740P1 0000 AA DD C
Screw(4×10) ﾋﾞｽ
30 LPL TP0499 QSZZ AD DJ C
Operation panel side plate left 操作ﾊﾟﾈﾙ側板左
31 LPL TP0498 QSZZ AE DJ C
Operation panel side plate right 操作ﾊﾟﾈﾙ側板右
32
CPNLH0 073 QS01 AZ FQ C
Key sheet [English for FAX(MX-M Series)] ｷｰｼｰﾄ
CPNLH0 073 QS02 AP EQ C
Key sheet [English no FAX(MX-M Series)] ｷｰｼｰﾄ
CPNLH0 073 QS03 AP EQ C
Key sheet [French for FAX(MX-M Series)] ｷｰｼｰﾄ
CPNLH0 073 QS04 AS EQ C
Key sheet [French no FAX(MX-M Series)] ｷｰｼｰﾄ
CPNLH0 073 QS22 AN EQ C
Key sheet [English(AR-57 Series)] ｷｰｼｰﾄ
CPNLH0 073 QS23 AZ FX C
Key sheet [French(AR-57 Series)] ｷｰｼｰﾄ
501 CHL DZ0118 RS5 1 -BXRR E
LCD unit [Missing parts code] LCD ﾕﾆｯﾄ
1st lot
(Unit)
901
CPNLC0 070 RS51 CC UB E
Operation panel unit [MX-M Series(North America,
Australia,New Zealand,Philippines,Thailand,
Indonesia,India,Special country)] 操作ﾊﾟﾈﾙﾕﾆｯﾄ
CPNLC0 070 RS53 CC UB E
Operation panel unit [MX-M Series(Europe,U.kingdom)] 操作ﾊﾟﾈﾙﾕﾆｯﾄ
CPNLC0 070 RS52 CC UB E
Operation panel unit [MX-M260FP/M310FP] 操作ﾊﾟﾈﾙﾕﾆｯﾄ
CPNLC0 070 RS54 CC UB E
Operation panel unit [MX-M260FG/M310FG] 操作ﾊﾟﾈﾙﾕﾆｯﾄ
5
