Sharp AR-5726 - ZMX-RP10 外装部 1(MX-RP10 RSPF Exteriors 1)

– 57 –
Update : 2009/11/16
Z
MX-RP10 外装部 1(MX-RP10 Exteriors 1)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 GCA B-0 075QST 1 AR EQ D
Rear cabinet 後ｷｬﾋﾞ
2 XEB S74 0P1200 0 AA DD C
Screw(4×12) ﾋﾞｽ
3 XHB S73 0P0800 0 AB DD C
Screw(3×8) ﾋﾞｽ
4 LST PP0 016QSZ Z AC DJ C
Stopper ｽﾄｯﾊﾟｰ
5 PCL C-0 023QSZ Z AS EQ B
SPF paper feed clutch SPF 給紙ｸﾗｯﾁ
6 NPL YZ0 033QSZ Z AD DJ C
Coupling pulley(39P) ｶｯﾌﾟﾘﾝｸﾞﾌﾟｰﾘｰ
7 CGI DM0 106RS5 3 -BXTF E
SPF Transport unit [Missing parts code] 搬送ﾕﾆｯﾄ RSPF
1st lot
8 XHB S73 0P1000 0 AD DD C
Screw(3×10) ﾋﾞｽ
9 GCA B-0 074QST 1 AH DX D
Front cabinet 前ｷｬﾋﾞ
10 MHN G-0021 QSZZ AX FG C
SPF hinge L SPF ﾋﾝｼﾞ L
11 MHN G-0022 QSZZ AX FG C
SPF hinge R SPF ﾋﾝｼﾞ R
12 XWV S740-0 5000 AA DD C
Washer ｷｸﾜｯｼｬ
13 NBR GC0018 QSZZ AD DJ C
Bearing 軸受
14 LSO U-0037 QST1 BD GJ C
Base tray ﾍﾞｰｽﾄﾚｲ
15 PCU SS0022 QSZ3 AW EQ C
OC mat OC ﾏｯﾄ
16 PSH EZ0413 QSZZ AD DJ C
OC mat sheet R OC ﾏｯﾄｼｰﾄ R
17 PSH EZ0077 QSZ1 AE DJ C
OC mat sheet F OC ﾏｯﾄｼｰﾄ F
18 XEB S730P0 8000 AC DD C
Screw(3×8) ﾋﾞｽ
19 LPL TP0321 QSZZ AE DS C
Width detect sensor fixing plate 幅検知ｾﾝｻｰ
取付板
20 GCA B-0078 QST1 AV FG D
Original tray lower cabinet TLPD 原稿ﾄﾚｲ下ｷｬﾋﾞ
TLPD
21 LSO U-0039 QSZ1 AN EQ C
Original tray S 原稿ﾄﾚｲ S
22 MLE VP0098 QSZZ AC DJ C
Original detect actuator 原稿検知
ｱｸﾁｭｴｰﾀｰ
23 VHP GP1S73 P+-18 AF DS B
Photo sensor(GP1S73P) ﾌｫﾄｾﾝｻｰ
24 CPW BF0160 QSE1 AS EQ E
SPF VR PWB SPF VR 基板
25 NGE RP0168 QSZZ AD DJ C
Pinion gear(36T) 幅検知ﾋﾟﾆｵﾝ
26 NGE RR0169 QSZZ AE DS C
Width detect rack gear TLPD 幅検知ﾗｯｸ TLPD
27 MSP RC0250 QSZZ AC DJ C
Tray lock spring ﾄﾚｲﾛｯｸｽﾌﾟﾘﾝｸﾞ
28 PTM E-0271 FCZZ AD DJ C
Tray lock pawl ﾄﾚｲﾛｯｸ爪
29 XEP S730P0 8X00 AA DD C
Screw(3×8X) ﾋﾞｽ
30 MSP RP0315 QSZZ AD DJ C
Regulation plate spring 規制板ｽﾌﾟﾘﾝｸﾞ
31 LSO U-0038 QST2 AW FG C
Original tray TLPD 原稿ﾄﾚｲ TLPD
32 LSO U-0041 QST1 AP EQ C
Middle tray TLPD 中間ﾄﾚｲ TLPD
33 LPL TP0319 QSN1 AG DX C
Regulation plate F TLPD 規制板 F TLPD
34 LPL TP0320 QSN1 AG DX C
Regulation plate R TLPD 規制板 R TLPD
35 DHA I-0468 QSZZ AH DX C
Original tray harness 原稿ﾄﾚｲﾊｰﾈｽ
37 CCL EZ0020 QS01 AK EB C
SPF glass cleaner SFP ｶﾞﾗｽｸﾘｰﾅｰ
501 CSO U-0037 RS5 3 CD UD E
Base tray unit(Include Block 31-501) ﾍﾞｰｽﾄﾚｲﾕﾆｯﾄ
( ﾌﾞﾛｯｸ 31-501
含む )
502 CSO U-0038 RS5 3 CE UH E
Original tray unit 原稿ﾄﾚｲﾕﾆｯﾄ
