Sharp AR-5726 - MX-Rp10 給紙部

– 61 –
Update : 2009/11/16
\
MX-RP10 給紙部 (MX-RP10 Paper feeding section)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 GCA B-0 076QST 1 AN EG D
Open/close cabinet 開閉ｷｬﾋﾞ
2 NGE RH0 166QSZ Z AC DJ C
Paper feed shaft gear(20T) 給紙軸ｷﾞﾔ
3 PCL C-0 316FCP 1 AP EQ B
Torque limiter ﾄﾙｸﾘﾐｯﾀｰ
4 MLN KP0 001QSZ Z AD DJ C
Pick up link TLPD 呼込みﾘﾝｸ TLPD
5 MSP RD0 309QSZ Z AC DJ C
Pick up arm spring 呼込みｱｰﾑ
ｽﾌﾟﾘﾝｸﾞ
6 NGE RH0 167QSZ Z AD DJ C
Paper feed drive gear(32T) 給紙駆動ｷﾞﾔ
7 NBR GM0 096FCZ 1 AC DJ C
Bearing 軸受
9 XRE SP5 0-0600 0 AA DD C
E type ring(E5) E ﾘﾝｸﾞ
10 NSF TB0075 QSZ1 -AFEG C
Paper feed roller shaft [Missing parts code] 給紙ﾛｰﾗｰ軸
1st lot
11 XPS SP20-0 7000 AA DD C
Spring pin(φ2-7) ｽﾌﾟﾘﾝｸﾞﾋﾟﾝ
12 LPL TM0318 QSZZ AC DJ C
Paper feed earth plate 給紙ｱｰｽ板
13 XEB S730P0 8000 AC DD C
Screw(3×8) ﾋﾞｽ
14 MSP RD0314 QSZZ AD DJ C
JAM release spring R TLPD JAM 解除
ｽﾌﾟﾘﾝｸﾞ R TLPD
15 NSF TZ0074 QSZ2 -AMEB C
Paper feed shaft [Missing parts code] 給紙入力軸
1st lot
17 NBR GC0018 QSZZ AD DJ C
Bearing(φ8) 軸受
18 NPL YZ0033 QSZZ AD DJ C
Coupling pulley(39P) ｶｯﾌﾟﾘﾝｸﾞﾌﾟｰﾘｰ
19 PCL C-0023 QSZZ AS EQ B
SPF paper feed clutch SPF 給紙ｸﾗｯﾁ
20 MAR MM0047 QSZZ AE DJ C
U-turn paper guide arm R U ﾀｰﾝ
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
ｱｰﾑ R
21 LST PP0016 QSZZ AC DJ C
Resin E ring(E5) 樹脂 E ﾘﾝｸﾞ
22 DHA I-0390 QSZZ AC DJ C
U-turn earth harness U ﾀｰﾝｱｰｽﾊｰﾈｽ
23 PGI DM0105 QSZ1 AQ EQ C
U-turn paper guide TLPD U ﾀｰﾝ
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
TLPD
24 GCA B-0077 QST1 AP EQ D
U-turn paper guide cabinet U ﾀｰﾝ
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
ｷｬﾋﾞ
26 MSP RP0311 QSZZ AC DJ C
PS sub tension spring PS 従動
ﾃﾝｼｮﾝｽﾌﾟﾘﾝｸﾞ
27 PTM E-0029 QST1 AE DJ C
U-turn paper guide lock pawl TLPD U ﾀｰﾝ
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
ﾛｯｸ爪 TLPD
28 MSP RD0310 QSZZ AC DJ C
U-turn paper guide lock spring TLPD U ﾀｰﾝ
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
ﾛｯｸｽﾌﾟﾘﾝｸﾞ
TLPD
29 NRO LP1517 FCZZ AA DJ B
Transport sub roller 搬送従動ﾛｰﾗｰ
30 NSF TZ0009 QSP1 AE DJ C
Transport sub shaft 搬送従動軸
31 MAR MP0046 QSZZ AD DJ C
U-turn paper guide arm F U ﾀｰﾝ
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
ｱｰﾑ F
32
PCOVP0 094 QSZZ AD DJ C
Maintenance cover ﾒﾝﾃﾅﾝｽｶﾊﾞｰ
PCOVP0 094 QSZ1 1ADDJ C
Maintenance cover ﾒﾝﾃﾅﾝｽｶﾊﾞｰ
09/12
34 CSF TB0073 QS01 AF DS E
Pick up roller shaft ASS’Y 呼び込みﾛｰﾗｰ軸
組品
35 MAR MP0044 QSZ1 AF DS C
Pick up arm 呼び込みｱｰﾑ
36
LFRM-0 069 QSZ1 AQ EQ C
Paper feed frame TLPD 給紙ﾌﾚｰﾑ TLPD
LFRM-0 069 QSZ2 1AQEQ C
Paper feed frame TLPD 給紙ﾌﾚｰﾑ TLPD
09/12
37 NCP L-0049 FCBZ AT EZ C
1way coupling 1way ｶｯﾌﾟﾘﾝｸﾞ
38 NPL YZ0035 QSZZ AD DJ C
Paper feed roller pulley(16P) 給紙ﾛｰﾗｰﾌﾟｰﾘｰ
39 NRO LR0166 QSZZ -AXFG B
Paper feed roller [Missing parts code] 給紙ﾛｰﾗｰ
1st lot
40 NRO LR1542 FCZZ AH DX B
Pick up roller 呼込みﾛｰﾗｰ
41 NPL YZ0034 QSZZ AD DJ C
Pick up roller pulley(16P) 呼込みﾛｰﾗｰ
ﾌﾟｰﾘｰ
42 NBL TT0033 QSZZ AF DS B
Drive belt 駆動ﾍﾞﾙﾄ
43 VHP GP1S73 P+-18 AF DS B
Photo sensor(GP1S73P) ﾌｫﾄｾﾝｻｰ
44 DHA I-0469 QSZZ AG DX C
Paper feed unit harness 給紙ﾕﾆｯﾄﾊｰﾈｽ
45 PSH EZ0444 QSZZ AE DS C
Pick up sheet 呼び込みｼｰﾄ
46 MLE VP0097 QSZZ AC DJ C
Original detect actuator 原稿検知
ｱｸﾁｭｴｰﾀｰ
47 LST PP0015 QSZZ AC DJ C
Stopper ｽﾄｯﾊﾟｰ
48 MLE VP0096 QSZZ AC DJ C
Stopper release lever ｽﾄｯﾊﾟｰ解除ﾚﾊﾞｰ
49 MAR MP0045 QSZZ AC DJ C
Stopper arm ｽﾄｯﾊﾟｰｱｰﾑ
50 MSP RD0313 QSZZ AC DJ C
JAM release spring F JAM 解除
ｽﾌﾟﾘﾝｸﾞ F
51 PSH EZ0407 QSZZ AB DJ C
PS guide sheet PS ｶﾞｲﾄﾞｼｰﾄ
52 VHP SG2481 ++-1 AE DS B
Photo sensor(SG2481) ﾌｫﾄｾﾝｻｰ
53 LHL DZ0153 QSZZ AC DJ C
SPF pick up sub holder SPF 呼込み
補助ﾎﾙﾀﾞｰ
54 PML T-0095 QSZZ AB DJ C
Pick up arm cushion 呼込みｱｰﾑﾓﾙﾄ
501 CCA B-0077 RS5 3 BP LP E
U-turn paper guide unit U ﾀｰﾝ
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
ﾕﾆｯﾄ
61
