– 27 –
Update : 2009/10/16
J
ﾏﾙﾁ手差し給紙ﾕﾆｯﾄ (Multi manual paper feed unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 PCO VP0 107QST F AL EB D
Multi frame cover N1 ﾏﾙﾁﾌﾚｰﾑｶﾊﾞｰ N1
2 XEB S73 0P1000 0 AC DD C
Screw(3×10) ﾋﾞｽ
3 PSH EZ0 099QSZ Z AC DJ C
Protect sheet S 防振ｼｰﾄ S
4 NRO LR0 922FCZ 2 AR ZZ C
Manual paper feed roller 手差しﾛｰﾗｰ
5 NGE RH0 223QSZ Z AC DJ C
Gear(20T) ｷﾞﾔ
6 XPS SJ2 0-0700 0 AA DD C
Spring pin(φ2-7) ｽﾌﾟﾘﾝｸﾞﾋﾟﾝ
7 NGE RH0 061QSZ Z AD DJ C
Gear(24T) ｷﾞﾔ
8 MAR MP0 009QSZ 1 AF DS C
Roller arm ﾛｰﾗｰｱｰﾑ
9 MSP RT0 351QSZ Z AC DJ C
Roller arm spring ﾛｰﾗｰｱｰﾑｽﾌﾟﾘﾝｸﾞ
10 NRO LR1267 FCZ1 AH DX C
Pick up roller 呼込みﾛｰﾗｰ
11 NSF TZ0096 QSZ1 AF DS C
Roller shaft F N ﾛｰﾗｰｼｬﾌﾄ F N
12 XRE SP40-0 6000 AA DD C
E type ring(E4) E ﾘﾝｸﾞ
13 LBS HZ0303 FCZZ AC DJ C
M bushing C M ﾌﾞｯｼﾝｸﾞ C
14 LBO SZ0150 QSZZ AE DS C
Cam boss A2 N ｶﾑﾎﾞｽ A2 N
15 MSP RC1315 FCZ1 AD DJ C
Manual paper feed clutch spring A 手差しｸﾗｯﾁ
ｽﾌﾟﾘﾝｸﾞ A
16 PPI PP0109 FCZ1 AC DJ C
Manual paper feed clutch sleeve A pipe 手差しｸﾗｯﾁ
ｽﾘｰﾌﾞ A ﾊﾟｲﾌﾟ
17 LBO SZ0199 QSZZ AE DS C
Cam boss A1 ｶﾑﾎﾞｽ A1
18 MAR MP0041 QSZZ AE DS C
Cam transmission arm ｶﾑ伝達ｱｰﾑ
19 MAR MP0006 QSZZ AD DJ C
Fulcrum arm ﾃｺｱｰﾑ
20 MSP RD0347 QSZZ AD DJ C
Stopper arm spring ｽﾄｯﾊﾟｰｱｰﾑ
ｽﾌﾟﾘﾝｸﾞ
21 MCA MP0003 QSZZ AD DJ C
Drive cam 駆動ｶﾑ
22 MSP RC1316 FCZ1 AE DS C
Manual paper feed clutch spring B 手差しｸﾗｯﾁ
ｽﾌﾟﾘﾝｸﾞ B
23 PPI PP0014 QSZZ AC DJ C
Cam clutch sleeve ｶﾑｸﾗｯﾁｽﾘｰﾌﾞ
25 NSF TZ0017 QSP1 AD DJ C
Manual paper feed cum shaft 手差しｶﾑｼｬﾌﾄ
26 NGE RH0972 FCZZ AB DJ C
Gear(27T) ｷﾞﾔ
27 CPL TM0345 QS01 AG DX C
Paper feed connect plate TLPD 給紙接続板
TLPD
29 XEB S730P0 8000 AC DD C
Screw(3×8) ﾋﾞｽ
30 PTM E-0178 FCZ1 AC DJ C
Manual paper feed pawl A 手差しﾗｯﾁ A
31 MSP RC2175 FCZZ AA DJ C
Pawl A spring 爪 A ｽﾌﾟﾘﾝｸﾞ
32
RPLU-0 028 QSZZ AM EG B
Multi field solenoid ﾏﾙﾁﾌｲｰﾙﾄﾞ
ｿﾚﾉｲﾄﾞ
RPLU-0 028 QSPZ 1AMEG B
Multi field solenoid ﾏﾙﾁﾌｲｰﾙﾄﾞ
ｿﾚﾉｲﾄﾞ
09/09
33 MSP RC1318 FCZ1 AA DJ C
Manual paper feed spring B 手差しｽﾌﾟﾘﾝｸﾞB
34 PTM E-0179 FCZZ AC DD C
Manual paper feed pawl B 手差しﾗｯﾁ B
35 XBB S730P1 0000 AA DD C
Screw(3×10) ﾋﾞｽ
36 MAR MP0027 QSZ1 AE DJ C
Manual paper feed tray arm 手差しﾄﾚｲｱｰﾑ
37 LFR M-0048 QSTH AS EQ D
Multi frame ﾏﾙﾁﾌﾚｰﾑ
38 MAR MP0008 QSZZ AH DX C
Stopper arm ｽﾄｯﾊﾟｰｱｰﾑ
39 LPL TP0056 QSZ3 AD DJ C
Stopper plate ｽﾄｯﾊﾟｰﾌﾟﾚｰﾄ
40 XEP S730P0 6X00 AA DD C
Screw(3×6X) ﾋﾞｽ
41 XEB S730P1 0000 AC DD C
Screw(3×10) ﾋﾞｽ
42 PSH EZ0241 QSZZ AB DJ C
Manual paper feed protection sheet 手差し防振ｼｰﾄ
43 LBN DJ0013 FCZ1 AE DJ C
Band 結束ﾊﾞﾝﾄﾞ
44 NSF TZ0090 QSZZ AG DX C
Roller shaft R N ﾛｰﾗｰ軸 R N
45 MSP RD0302 QSZZ AC DJ C
Manual paper feed coupling spring 手差しｶｯﾌﾟﾘﾝｸﾞ
ｽﾌﾟﾘﾝｸﾞ
46 MSP RD0329 QSZZ AC DJ C
Revers ACT spring 反転 ACT
ｽﾌﾟﾘﾝｸﾞ
47 NCP L-0012 QSZZ AD DJ C
Manual paper feed coupling 手差しｶｯﾌﾟﾘﾝｸﾞ
48 CPW BF0083 QSE5 AU EZ E
Sensor PWB ｾﾝｻｰ基板
49 DHA I-0360 QSPZ AE DJ C
DUP 2 sensor harness DUP2 ｾﾝｻｰﾊｰﾈｽ
50 MLE VP0104 QSZZ AD DJ C
Revers lever 反転ﾚﾊﾞｰ
51 LBS HZ0006 QSZZ AC DJ C
M bushing 2 M ﾌﾞｯｼﾝｸﾞ 2
52 LST PP0011 QSZZ AC DJ C
Resin E type ring 樹脂 E ﾘﾝｸﾞ
53 LX- WZ0011 QSZZ AB DD C
Poly slider(5-12-0.5) ﾎﾟﾘｽﾗｲﾀﾞｰ
(Unit)
901 CFR M-0048 RS5 5 BE GN E
Multi manual paper feed unit(Without No.36,40,41,43) ﾏﾙﾁ手差しﾕﾆｯﾄ
(No.36,40,41,43
を除く )
27
