– 33 –
Update : 2009/10/16
M
定着ﾕﾆｯﾄ 1(Fusing unit 1)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 MAR MP0 048QSZ 2 -AFDS C
Pressure release fulcrum arm [Missing parts code] 圧解支点ｱｰﾑ
1st lot
2 MLE VP0 100QSZ Z AE DS C
Pressure release lever F TL 圧解ﾚﾊﾞｰ F TL
3 MLE VP0 101QSZ Z AE DS C
Pressure release lever R TL 圧解ﾚﾊﾞｰ R TL
8 RTH M-0 050FCZ Z AN EG B
Thermostat TL ｻｰﾓｽﾀｯﾄ TL
10 DHA I-0367 QSPZ AE DJ C
DUP sensor harness DUP ｾﾝｻｰﾊｰﾈｽ
11 LHL DW0086 QSZZ AB DJ C
Harness ring ﾊｰﾈｽﾘﾝｸﾞ
12 RH- HX0001 QSLB AT EZ B
Thermistor TL ｻｰﾐｽﾀ TL
13 LPL TM0338 QSZ1 AC DJ C
Fusing earth plate UR 定着ｱｰｽ板 UR
14 VHP GP1SQ7 3P-18 AF DS B
Photo sensor(GP1SQ73P) ﾌｫﾄｾﾝｻｰ
15
XEBS73 0P0 6000 AA DD C
Screw(3×6) ﾋﾞｽ
XEBS73 0P0 6000 -AADD C
Screw(3×6) [To No,51] ﾋﾞｽ (3×6)
09/07 mid
18 LST PF0172 FCZZ AA DD C
Roller stopper ﾛｰﾗｰｽﾄｯﾊﾟｰ
!
19
RLMPU0 040 QSPZ BA FX B
Heater lamp (120V) ﾋｰﾀｰﾗﾝﾌﾟ
! RLMPU0 041QSP Z BA FX B
Heater lamp (230V) ﾋｰﾀｰﾗﾝﾌﾟ
! RLMPU0 039QSP Z BA FX B
Heater lamp (100V) ﾋｰﾀｰﾗﾝﾌﾟ
22 LHL DZ0139 QSZZ AD DJ C
Lamp fixing plate ﾗﾝﾌﾟ取付板
23 LFR M-0098 QSZZ AV FG D
Fusing upper frame(TL) 定着上ﾌﾚｰﾑ
24 MSP RC0323 QSZZ AC DJ C
Fusing unit earth spring 定着ﾕﾆｯﾄ
ｱｰｽｽﾌﾟﾘﾝｸﾞ
25 LPL TM0337 QSZ1 AC DJ C
Fusing earth plate UF 定着ｱｰｽ板 UF
27 NRO LM0129 QSZZ BB FX A
Heat roller(TL) ﾋｰﾄﾛｰﾗｰ
28 NGE RH0171 QSZZ AR EQ A
Fusing gear(TL)(38T) 定着ｷﾞﾔ
29 NBR GP0025 QSZZ AN EQ A
Upper HR bearing(TL) 上 HR 軸受
30 LPL TM0343 QSZZ AB DJ C
Gear key plate(TL) ｷﾞﾔｷｰ板
31 CPL TM0336 QS02 AR EQ A
Fusing cleaner plate 定着ｸﾘｰﾅ板
32 MSP RT0257 QSZ1 AC DJ C
Upper pawl spring 上爪ｽﾌﾟﾘﾝｸﾞ
33 MSP RD0322 QSZZ AC DJ C
Fusing ACT return spring 定着 ACT
復帰ｽﾌﾟﾘﾝｸﾞ
34 MLE VP0099 QSZ1 AF DS C
Fusing rear paper detect lever 定着後用紙
検知ﾚﾊﾞｰ
35 PGI DM0113 QSZZ AT EZ C
Fusing rear upper guide 定着後上 PG
36 PTM E-0282 FCZ2 AH DX A
Upper separate pawl 上剥離爪
37 LX- WZ0006 QSZZ AC DD C
Washer 剥離爪ﾜｯｼｬ
38 PTM E-0024 QSZ2 AN EQ A
Upper separate pawl 上剥離爪 LPD
39 LX- BZ0086 QSPZ AD DJ C
Fusing unit fixing screw 定着ﾕﾆｯﾄ
取付ﾋﾞｽ
40 CPL TM0513 QS01 -AFDS A
Thermistor felt fixing plate [Missing parts code] ｻｰﾐｽﾀﾌｪﾙﾄ
取付板
1st lot
41 LX- BZ1195 FCZZ AC DD C
Screw(M3) ﾋﾞｽ
42 LST YM0004 QSZZ AK DX C
Fusing upper frame stay And3 定着上ﾌﾚｰﾑｽﾃｲ
And3
43 LPL TM0510 QSZZ AD DJ C
Earth joint plate ｱｰｽ連結板
44 LX- BZ1181 FCZZ AB DD C
Screw(3×6) ﾋﾞｽ
45 LPL TM0473 QSZZ AE DJ C
Fusing earth plate And3 定着ｱｰｽ板 And3
46 LX- BZ1126 FCPZ AB DD C
Thermister screw ｻｰﾐｽﾀﾋﾞｽ
47 XHP S730P0 4000 AB DD C
Screw(3×4) ﾋﾞｽ
48 XWH S730-0 5080 AA DD C
Washer ﾋﾗﾜｯｼｬ
49 LX- BZ0093 QSZZ AC DD C
Screw ﾋﾞｽ
50 PCO VP0148 QSZZ AK DX C
Thermostat cover ｻｰﾓｽﾀｯﾄｶﾊﾞｰ
51 XBB S730P0 6000 -ACDD C
Screw(3×4) [From No,15] ﾋﾞｽ (3×4)
1st lot
(Unit)
901
DUNTW0 782 RSZZ BW RJ E
Fusing unit(Include Block 18) (120V) 定着ﾕﾆｯﾄ
( ﾌﾞﾛｯｸ 18 含む )
DUNTW0 782 RS12 BW RJ E
Fusing unit(Include Block 18) (230V) 定着ﾕﾆｯﾄ
( ﾌﾞﾛｯｸ 18 含む )
DUNTW0 782 RS11 BW RJ E
Fusing unit(Include Block 18) (100V) 定着ﾕﾆｯﾄ
( ﾌﾞﾛｯｸ 18 含む )
33
