Sharp AR-5726 - Page 162

– 35 –
Update : 2009/11/16
N
定着ﾕﾆｯﾄ 2(Fusing unit 2)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 NBR GY0 022QSZ Z AL EB A
Fusing pressure bearing FU 加圧軸受
2 NRO LR0 156QSZ Z BF GN A
Fusing roller 圧着ﾛｰﾗｰ
3 MSP RC0 324QSZ Z AC DJ C
Fusing pressure spring(TL) 定着加圧
ｽﾌﾟﾘﾝｸﾞ
5 LPL TM0 341QSZ 1 AC DJ C
Fusing earth plate(DR) 定着ｱｰｽ板
7 LPL TM0 531QSZ Z -ACDJ C
High resistor eatrh plate And3 [Missing parts code] ﾊｲﾚｼﾞｱｰｽ板
And3
1st lot
8 PGI DH0 140QSZ Z AY FQ A
Fusing front guide 定着前ｶﾞｲﾄﾞ
9 LPL TM0 340QSZ Z AC DJ C
Fusing earth plate(DF) 定着ｱｰｽ板
11 MSP RD0328 QSZ1 AC DJ C
Lower pawl spring R(TL) 下爪ｽﾌﾟﾘﾝｸﾞ R
12 PTM E-0041 QSZZ AG DS A
Lower separate pawl 下剥離爪
13
TCAUH0 017 QSZ1 AC DJ D
High temperature caution label (Except Japan) 高温注意ﾗﾍﾞﾙ
TLABH0 381 QSZZ AE DJ D
High temperature caution label (Japan) 高温注意ﾗﾍﾞﾙ
14 XBP SN30P0 8KS0 AA DD C
Screw(3×8KS) ﾋﾞｽ
15 MSP RD0327 QSZ1 AC DJ C
Lower pawl spring F(TL) 下爪ｽﾌﾟﾘﾝｸﾞ F
16 LFR M-0072 QSZ5 -ATEQ D
Fusing lower frame [Missing parts code] 定着下ﾌﾚｰﾑ
1st lot
17 MSP RD0326 QSZZ AC DJ C
Fusing rear lower guide spring 定着後下ｶﾞｲﾄﾞ
復帰ｽﾌﾟﾘﾝｸﾞ
18 PGI DM0115 QSZZ AS EQ C
Fusing rear lower guide 定着後下ｶﾞｲﾄﾞ
19 TLA BH0289 QSZZ AA DJ D
Fusing green label 定着ｸﾞﾘｰﾝﾗﾍﾞﾙ
20 MLE VF0111 QSZZ AD DJ C
Pressure lever F(AND2) 加圧ﾚﾊﾞｰ F
21 MLE VF0112 QSZZ AD DJ C
Pressure lever R(AND2) 加圧ﾚﾊﾞｰ R
22
TLABH0 685 QSZZ AD DJ D
High temperature caution label (Except Japan) 高温注意ﾗﾍﾞﾙ
TLABH0 683 QSZZ AE DJ D
High temperature caution label (Japan) 高温注意ﾗﾍﾞﾙ
23 VRH -ST2HB 507K -ADDJ C
Resistor(500MΩ) [Missing parts code] 抵抗 (500MΩ)
09/07 mid
24 XWH S740-0 8090 AA DD C
Washer ﾜｯｼｬｰ
(Unit)
901
DUNTW0 782 RSZZ BW RJ E
Fusing unit(Include Block 17) (120V) 定着ﾕﾆｯﾄ
( ﾌﾞﾛｯｸ 17 含む )
DUNTW0 782 RS12 BW RJ E
Fusing unit(Include Block 17) (230V) 定着ﾕﾆｯﾄ
( ﾌﾞﾛｯｸ 17 含む )
DUNTW0 782 RS11 BW RJ E
Fusing unit(Include Block 17) (100V) 定着ﾕﾆｯﾄ
( ﾌﾞﾛｯｸ 17 含む )
35
