Sharp AR-5726 - Page 164

– 37 –
Update : 2009/11/16
O
駆動ﾕﾆｯﾄ (Drive unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 XBP S74 0P08ES 0 AB DD C
Screw(4×8ES) ﾋﾞｽ
2 RMO TP0 069QSP Z BA FX B
Main motor ﾒｲﾝﾓｰﾀｰ
3 CPL TM0 160QS0 2 AU FG C
Main drive plate ﾒｲﾝ駆動板
4 MSP RC0 200QSZ 1 AB DJ C
Ratchet spring ﾗﾁｪｯﾄｽﾌﾟﾘﾝｸﾞ
5 NGE RH0 234QSZ Z AF DS C
Ratchet gear(49T) ﾗﾁｪｯﾄｷﾞﾔ
6 NGE RH0 090QSZ 1 AF DS C
Fusing drive gear(19T) 定着駆動ｷﾞﾔ
7 NGE RH0 084QSZ Z AK DX C
Gear(94/21T) ｷﾞﾔ
8 XRE SP7 0-0800 0 AA DD C
E type ring(E7) E ﾘﾝｸﾞ
9 NGE RH0 192QSZ Z AD DJ C
Gear(46/19T) ｷﾞﾔ
10
NGERH0 086 QSZZ AD DJ C
Gear(39/21T) [MX-M260/M260N/M260FP/M260FG,
AR-5726] ｷﾞﾔ
NGERH0 190 QSZZ AC DJ C
Gear(39/19T) [MX-M310/M310N/M310FP/M310FG,
AR-5731] ｷﾞﾔ
11
NGERH0 087 QSZZ AE DJ C
Gear(30/21T) [MX-M260/M260N/M260FP/M260FG,
AR-5726] ｷﾞﾔ
NGERH0 189 QSZZ AD DJ C
Gear(30/21T) [MX-M310/M310N/M310FP/M310FG,
AR-5731] ｷﾞﾔ
12 NGE RH0010 QSZZ AD DJ C
Gear(28T) ｷﾞﾔ
13 NGE RH0092 QSZZ AD DJ C
Gear(30/16T) ｷﾞﾔ
14 NGE RH0093 QSZZ AD DJ C
Gear(28/16T) ｷﾞﾔ
15 XBP S730P0 6KS0 AB DD C
Screw(3×6KS) ﾋﾞｽ
16 NGE RH0095 QSZZ AE DJ C
Gear ｷﾞﾔ
17 NGE RH0191 QSZZ AC DJ C
MG gear MG ｷﾞﾔ
18 NGE RH0186 QSZZ AH DX C
N gear(58/21T) N ｷﾞﾔ
19 NGE RH0096 QSZZ AE DJ C
Gear(37/25T) ｷﾞﾔ
20 CPL TM0161 QS02 AP EQ C
Sub drive plate ｻﾌﾞ駆動板
21 MSP RC0262 QSZ1 AC DJ C
MG spring MG ｽﾌﾟﾘﾝｸﾞ
22 NCP L-0009 QSZZ AC DJ C
MG coupling MG ｶｯﾌﾟﾘﾝｸﾞ
23 NGE RH0091 QSZZ AE DJ C
Coupling gear(34T) ｶｯﾌﾟﾘﾝｸﾞｷﾞﾔ
24 CGE RH0204 RS51 AX FQ C
Drum coup gear ﾄﾞﾗﾑｶｯﾌﾟｷﾞﾔ
25 DHA I-0602 QSPZ AE DS C
AN2R main motor harness AN2R ﾒｲﾝﾓｰﾀｰ
ﾊｰﾈｽ
26 LX- WZ0012 QSZZ AB DD C
Poly slider AND2 ﾎﾟﾘｽﾗｲﾀﾞｰAND2
27 XRE SP50-0 6000 AA DD C
E type ring(E5) E ﾘﾝｸﾞ
28 LX- WZ0476 FCZZ AC DD C
Poly slider ﾎﾟﾘｽﾗｲﾀﾞｰ
29 LX- WZ0407 FCZZ AB DD C
Poly slider ﾎﾟﾘｽﾗｲﾀﾞｰ
(Unit)
901
CPLTM0 160 RS59 BH HC E
Drive unit [MX-M260/M260N/M260FP/M260FG,
AR-5726] 駆動ﾕﾆｯﾄ
CPLTM0 160 RS60 BH HC E
Drive unit [MX-M310/M310N/M310FP/M310FG,
AR-5731] 駆動ﾕﾆｯﾄ
37
