– 41 –
Update : 2009/11/16
Q
第一排紙ﾕﾆｯﾄ 2(1st delivery paper unit 2)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 XHB S73 0P0800 0 AB DD C
Screw(3×8) (Except North America) ﾋﾞｽ
2 RMO TS0 071QSP Z BD GJ B
Shifter motor (Except North America) ｼﾌﾀｰﾓｰﾀｰ
3 CPL TM0 184QS0 3 AH DX C
Shifter drive plate (Except North America) ｼﾌﾀｰ駆動板
4 XEB S73 0P0800 0 AC DD C
Screw(3×8) ﾋﾞｽ
5 MSP RD0 225QSZ Z AC DJ C
Stopper return spring (Except North America) ｽﾄｯﾊﾟｰ復帰
ｽﾌﾟﾘﾝｸﾞ
6 LST PP0 003QSZ 1 AC DJ C
Shifter stopper (Except North America) ｼﾌﾀｰｽﾄｯﾊﾟｰ
7 NGE RH0 068QSZ 1 AD DJ C
Shifter gear(50T) (Except North America) ｼﾌﾀｰｷﾞﾔ
8 NGE RH0 067QSZ Z AD DJ C
Shifter gear(24T) (Except North America) ｼﾌﾀｰｷﾞﾔ
9 VHP GP1 A71L3- 18 AG DS B
Photo sensor(GP1A71L3) (Except North America) ﾌｫﾄｾﾝｻｰ
11 XRE SP30-0 6000 AA DD C
E type ring(E3) (Except North America) E ﾘﾝｸﾞ
12 XRE SP40-0 6000 AA DD C
E type ring(E4) (Except North America) E ﾘﾝｸﾞ
13 MSP RD0216 QSZZ AD DJ C
Shifter earth spring ｼﾌﾀｰｱｰｽｽﾌﾟﾘﾝｸﾞ
14 MSP RT0217 QSZ1 AC DJ C
Gate return spring ｹﾞｰﾄ復帰
ｽﾌﾟﾘﾝｸﾞ
15 LBR C-0002 QSZ1 AC DJ C
Gate bracket ｹﾞｰﾄﾌﾞﾗｹｯﾄ
16 LBS HZ0303 FCZZ AC DJ C
M bushing C M ﾌﾞｯｼﾝｸﾞ C
17 NBR GY2122 SCZZ AB DD C
Transport roller bearing 搬送ﾛｰﾗｰ軸受
18 NBR GC0019 QSZZ AD DJ C
Bearing(φ6) 軸受
19 XPS SJ30-0 8000 AA DD C
Spring pin(φ3-8) ｽﾌﾟﾘﾝｸﾞﾋﾟﾝ
20 NBL TT0024 QSZZ AG DS B
Drive belt 240 駆動ﾍﾞﾙﾄ 240
21 NGE RH0080 QSZZ AE DJ C
Delivery drive gear(25/31T) 排紙駆動ｷﾞﾔ
22 NGE RH0082 QSZZ AD DJ C
DUP delivery gear(20/31T) DUP 排紙ｷﾞﾔ
23 MSP RD0198 QSZZ AC DJ C
Delivery earth spring B 排紙ｱｰｽ
ｽﾌﾟﾘﾝｸﾞ B
24 NGE RH0113 QSZZ AC DJ C
Idle gear B(29T) ｱｲﾄﾞﾙｷﾞﾔ B
25 NGE RH0114 QSZZ AC DJ C
Idle gear C(29T) ｱｲﾄﾞﾙｷﾞﾔ C
26 MSP RD0196 QSZZ AC DJ C
Delivery earth spring A 排紙ｱｰｽ
ｽﾌﾟﾘﾝｸﾞ A
27 NGE RH0155 QSZZ AD DJ C
Gear(31/39T) ｷﾞﾔ
28
RPLU-0 027 QSZZ AU EZ B
Change gate solenoid 切替ｹﾞｰﾄｿﾚﾉｲﾄﾞ
RPLU-0 027 QSPZ 1AUEZ B
Change gate solenoid 切替ｹﾞｰﾄｿﾚﾉｲﾄﾞ
09/09
29 CBR C-0004 QS03 AF DS C
DUP motor fixing bracket DUP ﾓｰﾀｰ
取付ﾌﾞﾗｹｯﾄ
30 RMO TS0070 QSPZ BD GJ B
DUP motor DUP ﾓｰﾀｰ
31 XHB S730P0 8000 AB DD C
Screw(3×8) ﾋﾞｽ
32 XBB S726P0 3000 -AADD C
Screw(2.6×3) [Missing parts code] ﾋﾞｽ (2.6×3)
1st lot
33 XWH S730-0 5070 AA DD C
Washer ﾋﾗﾜｯｼｬ
34 LHL DW1334 FCZZ -AADJ C
Wire holder ｵﾒｶﾞﾛｯｸ
1st lot
35 PSH EZ0316 QSZZ AD DJ C
Delivery motor sheet 排紙ﾓｰﾀｰｼｰﾄ
36 PRD AZ0002 QSZZ AD DJ C
Delivery motor radiation plate 排紙ﾓｰﾀｰ放熱板
37 PSH EZ0341 QSZZ AA DJ C
Shifter stop mylar (Except North America) ｼﾌﾀｰｽﾄｯﾌﾟﾏｲﾗｰ
501 CPL TM0184 RS5 4 AX FG E
Shifter unit (Except North America) ｼﾌﾀｰﾕﾆｯﾄ
502 CBR C-0004 RS5 4 -BAFX E
DUP motor fixing bracket unit [Missing parts code] DUP ﾓｰﾀｰ
取付ﾌﾞﾗｹｯﾄﾕﾆｯﾄ
1st lot
(Unit)
901
CFRM-0 038 RS74 BP LP E
1st delivery unit(Include Block 20) (North America) 1st 排紙ﾕﾆｯﾄ
( ﾌﾞﾛｯｸ 20 含む )
CFRM-0 038 RS76 -BQLP E
1st delivery unit(Include Block 20) [Missing parts code] 1st 排紙ﾕﾆｯﾄ
(Except North America,Japan) ( ﾌﾞﾛｯｸ 20 含む )
1st lot
41
