– 43 –
Update : 2009/11/16
R
基板部 (PWB section)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1
CPWBX0 136 QS3L CB TX E
IMC PWB [MX-M260/M260N/M260FP/M260FG,
AR-5726] IMC 基板
CPWBX0 136 QS3M CB TX E
IMC PWB [MX-M310/M310N/M310FP/M310FG,
AR-5731] IMC 基板
2 XBB S73 0P0800 0 AA DD C
Screw(3×8) ﾋﾞｽ
3 PSP AB0 039QSZ Z AG DJ C
Spacer ｽﾍﾟｰｻｰ
4 CPW BF0 235QSE 1 BB GD E
Option interface PWB ｵﾌﾟｼｮﾝ中継基板
5 XBB S83 0P0800 0 AA DD C
Screw(3×8) ﾋﾞｽ
6 DHA I-0 611QSP Z -AVFG C
AN2R MCU-OP interface harness [Missing parts code] AN2R MCU-OP
中継ﾊｰﾈｽ
1st lot
7 LHL DZ0 062QSZ 2 AT EZ C
MCU PWB fixing plate MCU 基板
取付板
8 LX- BZ0 090QSP Z AE DD C
Hexagon screw 6 角ﾋﾞｽ
9 LHL DW0 086QSZ Z AB DJ C
Harness ring LPD ﾊｰﾈｽﾘﾝｸﾞ LPD
10
CPWBX0 233 QS31 CD UD E
MCU PWB [MX-M260 North America] MCU 基板
CPWBX0 233 QS32 CD UD E
MCU PWB [MX-M310 North America] MCU 基板
CPWBX0 233 QS33 CD UD E
MCU PWB [MX-M260/M260N/M260FP
/M260FG Except North America] MCU 基板
CPWBX0 233 QS34 CD UD E
MCU PWB [MX-M310/M310N/M310FP
/M310FG Except North America] MCU 基板
CPWBX0 233 QS35 CC UB E
MCU PWB [AR-5726] MCU 基板
CPWBX0 233 QS36 CC UB E
MCU PWB [AR-5731] MCU 基板
11 XBP S730P0 6KS0 AB DD C
Screw(3×6KS) ﾋﾞｽ
12 LHL DZ0071 QSZZ AG DX C
Mother board holder ﾏｻﾞｰﾎﾞｰﾄﾞﾎﾙﾀﾞｰ
13 CPW BN0137 QSE1 AZ FX E
Mother board ﾏｻﾞｰﾎﾞｰﾄﾞ
14 XHB S730P0 8000 AB DD C
Screw(3×8) ﾋﾞｽ
15 LX- BZ0082 QSPZ AA DD C
Screw(3×8) ﾋﾞｽ
16 LHL DZ0070 QSZ3 AW FG C
OP PWB holder OP 基板ﾎﾙﾀﾞｰ
17 XHB S730P0 8000 AB DD C
Screw(3×8) ﾋﾞｽ
18 XEB S740P1 0000 AA DD C
Screw(4×10) ﾋﾞｽ
19 XBP S730P0 8KS0 AB DD C
Screw(3×8KS) ﾋﾞｽ
20 PSH EZ0269 QSZZ AC DJ C
CCD harness sheet CCD ﾊｰﾈｽｼｰﾄ
22 DHA I-0345 QSZZ AG DX C
CCD harness CCD ﾊｰﾈｽ
23 CPW BX0140 QS3K CM UW E
FAX main PWB (Japan) FAX ﾒｲﾝ基板
24 CPW BN0174 QS31 BV MW E
LIU PWB (Japan) LIU 基板
25 RSP A00001 QSPZ AH DX B
Speaker (Japan) ｽﾋﾟｰｶｰ
26 XEP S730P0 6X00 AA DD C
Screw(3×6) (Japan) ﾋﾞｽ
27 LSU PP0001 QSZZ AC DJ C
Spacer(WLS18-0) ｽﾍﾟｰｻｰ
28 DHA I-0606 QSPZ -BTMW C
ILSW interface harness 2 [Missing parts code] ILSW中継ﾊｰﾈｽ 2
1st lot
29
CPWBX0 202 RS55 BZ TR E
PCL PWB [MX-M260N/M310N] PCL 基板
CPWBX0 202 RS54 CA TR E
PCL PWB [MX-M260FP/M310FP] PCL 基板
30 PCA PH0018 QSZZ AD DJ D
15P protect cap 15P 保護ｷｬｯﾌﾟ
31 PCA PH0019 QSZZ AE DJ D
25P protect cap
(Except North America,Japan,Argentina) 25P 保護ｷｬｯﾌﾟ
32 PCA PH0017 QSZZ AC DJ D
9P protect cap 9P 保護ｷｬｯﾌﾟ
33 CPW BN0135 QS34 -BSMW E
SPLC PWB [Missing parts code]
[MX-M260/M310/M260FG/M310FG,AR-5726/5731] SPLC 基板
1st lot
35
DHAI-0 591 QSP1 -BEGN C
1st delivery harness [Missing parts code]
(North America) 1st 排紙ﾊｰﾈｽ
1st lot
DHAI-0 601 QSP1 BE GN C
1st delivery harness (Except North America) 1st 排紙ﾊｰﾈｽ
37 DHA I-0200 QSZZ AS EZ C
CL harness CL ﾊｰﾈｽ
38
DHAI-0 347 QSPZ AN EQ C
Optical sensor harness (Inch Series) 光学ｾﾝｻｰﾊｰﾈｽ
DHAI-0 346 QSPZ AP EQ C
Optical sensor harness (AB Series) 光学ｾﾝｻｰﾊｰﾈｽ
39 DHA I-0506 QSPZ AQ EQ C
LSU interface harness LSU 中継ﾊｰﾈｽ
40 DHA I-0593 QSPZ -BFGN C
Drive/Manual paper feed interface harness 駆動 / 手差し
[Missing parts code] 中継ﾊｰﾈｽ
1st lot
41 DHA I-0350 QSPZ AG DX C
Cassette sensor PWB harness ｶｾｯﾄｾﾝｻｰ
基板ﾊｰﾈｽ
42 DHA I-0610 QSP1 BF GN C
Operation PWB FFC 操作基板 FFC
43 DHA I-0381 QSPZ AH DX C
Fusing interface harness 定着中継ﾊｰﾈｽ
44 DHA I-0594 QSPZ -BGGT C
AN2R power supply harness [Missing parts code] AN2R 電源ﾊｰﾈｽ
1st lot
55 TLA BH0533 QSZZ AB DJ D
USB label AND USB ﾗﾍﾞﾙ AND
56 TLA BH0534 QSZZ AB DJ D
NIC label AND [Except MX-M260FG/M310FG] NIC ﾗﾍﾞﾙ AND
70 RDT CH0161 FCP1 AV FG B
Temperature humidity sensor 温度湿度ｾﾝｻｰ
72 DHA I-0595 QSPZ AE DS C
Temperature humidity sensor harness 温度湿度ｾﾝｻｰ
ﾊｰﾈｽ
73 LSU PM0002 QSZZ AE DJ C
Support post [MX-M260N/M310N/M260FP/M310FP] ｻﾎﾟｰﾄﾎﾟｽﾄ
74
RCORF0 046 FCZZ AH DX C
Core ｺｱ
RCORF0 046 FCZZ -AHDX C
Core ｺｱ
1st lot
75 DHA I-0597 QSP1 -BFGN C
MCU-casette harness [Missing parts code] MCU- ｶｾｯﾄﾊｰﾈｽ
1st lot
80 DHA I-0590 QSPZ -BTNE C
DV interface harness [Missing parts code] DV 中継ﾊｰﾈｽ
1st lot
82
VHI29L 160 7DQS BB GD B
MCU ROM [MX-M260 North America] MCU ROM
VHI29L 160 7EQS BB GD B
MCU ROM [MX-M310 North America] MCU ROM
VHI29L 160 7QQS BA FX B
MCU ROM [MX-M260/M260N Except North America] MCU ROM
VHI29L 160 7PQS BA FX B
MCU ROM [MX-M310/M310N Except North America] MCU ROM
VHI29L 160 7TQS BA FX B
MCU ROM [MX-M260FG/M260FP] MCU ROM
VHI29L 160 7UQS BA FX B
MCU ROM [MX-M310FG/M310FP] MCU ROM
VHI29L 160 8MQS BA FX B
MCU ROM [AR-5726] MCU ROM
83
VHI29L 128 56QS BH HC B
PCL PRGDIMM [MX-M260N/M310N Philippines] PCL PRGDIMM
VHI29L 128 58QS BH HC B
PCL PRGDIMM[MX-M260N/M310N Except Philippines] PCL PRGDIMM
VHI29L 128 54QS BH HC B
PCL PRGDIMM [MX-M260FP/M310FP] PCL PRGDIMM
43
To Next Page
