– 45 –
Update : 2009/11/16
S
後ﾌﾚｰﾑ部 (Rear frame section)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 XBP SN4 0P06K0 0 AA DD C
Screw(4×6K) ﾋﾞｽ
2 DHA I-0 596QSP Z -BTMW C
AN2R HL interface harness [Missing parts code] AN2R HL
中継ﾊｰﾈｽ
1st lot
3 TLA BZ4 868FCZ 1 AB DJ D
Earth label (200V Series) ｱｰｽﾗﾍﾞﾙ
4 XHB S73 0P0600 0 AC DD C
Screw(3×6) ﾋﾞｽ
5 LPL TM0 162QSZ 1 AC DJ C
Drive earth plate 駆動ｱｰｽ板
6 LPL TM0 252QSZ Z AD DJ C
Paper feed earth plate LP 給紙ｱｰｽ板 LP
7 DHA I-0 593QSP Z -BFGN C
Drive/Manual paper feed interface harness 駆動 / 手差し
[Missing parts code] 中継ﾊｰﾈｽ
1st lot
8 DHA I-0 378QSP Z AC DJ C
Cassette earth harness ｶｾｯﾄｱｰｽﾊｰﾈｽ
9 XHB S73 0P0800 0 AB DD C
Screw(3×8) ﾋﾞｽ
10 XEB S740P3 0000 AC DD C
Screw(4×30) ﾋﾞｽ
11 PGI DM0184 QSZ1 AH DX C
Harness guide ﾊｰﾈｽｶﾞｲﾄﾞ
12 XEB S740P3 0000 AC DD C
Screw(4×30) ﾋﾞｽ
13 CDA IU0024 RS57 AZ FQ E
1st lift up unit 1st ﾘﾌﾄｱｯﾌﾟﾕﾆｯﾄ
15 LPL TM0249 QSZZ AC DJ C
2nd earth plate 2nd ｱｰｽ板
!
19
QACCD7 713 QCPZ AT EZ B
AC cord (North America) AC ｺｰﾄﾞ
!
QACCB7 623 QCPZ BB GD B
AC cord (U.kingdom,UAE,Yemen,Oman,Qutar,
Kuwait,Bahrain) AC ｺｰﾄﾞ
!
QACCVR 621 QCPZ AQ FQ B
AC cord (Germany,Switzerland,Europe,East Europe,
Algeria,Iran,Egypt,Syria,Tunisa,Nigeria,
West Africa,Morocco,Jordan,Lebanon) AC ｺｰﾄﾞ
! QACCZR 626QCP Z BB GD B
AC cord (Philippines) AC ｺｰﾄﾞ
! QACCZR 941QCP Z BB FX B
AC cord (Thailand,Indonesia) AC ｺｰﾄﾞ
! QACCB9 521QCZ Z AW FG B
AC cord (India,Special country,Malaysia,Singapore) AC ｺｰﾄﾞ
! QACCJ6 413QCP A AY FQ B
AC cord (Japan) AC ｺｰﾄﾞ
! QACCLR 624QCP Z BA FX B
AC cord (Australia,New Zealand) AC ｺｰﾄﾞ
! QACCR7 621QCZ Z AZ FQ B
AC cord (Argentina) AC ｺｰﾄﾞ
QPLGA4 171 CCPZ AR EQ B
Plug (India) ﾌﾟﾗｸﾞ
QPLGA0 001 QCZZ AN EQ B
Plug (Special country) ﾌﾟﾗｸﾞ
QPLGA0 009 QCPZ AR EQ B
Plug (Malaysia,Singapore) ﾌﾟﾗｸﾞ
PHOG-1 023 CCZZ AB DD B
Plug protector (India,Malaysia,Singapore) ﾌﾟﾗｸﾞ用保護
TCAUS0 009 QSZZ AF DS D
LAG Plug caution label (Argentina) LAG ﾌﾟﾗｸﾞ
注意ﾗﾍﾞﾙ
20 QSW -C9295 QCPZ AL EB B
Power supply switch(AJ8W200BF) 電源ｽｲｯﾁ
21 QSW -C9294 QCZZ AF DS B
Dehumidify heater switch (Japan) 除湿ﾋｰﾀｰｽｲｯﾁ
22 DHA I-0589 QSPZ BS MW C
Dehumidify heater switch harness (Japan) 除湿ﾋｰﾀｰ
ｽｲｯﾁﾊｰﾈｽ
23 DHA I-0545 QSPZ AH DX C
Dehumidify heater separate harness (Japan) 除湿ﾋｰﾀｰ
分岐ﾊｰﾈｽ
27 RCI LZ0016 QSZZ BE GN C
Reactle (200V) ﾘｱｸﾄﾙ
!
28
RDENC0 052 QSPZ BZ TF E
Low voltage power supply unit (120V) 低圧電源ﾕﾆｯﾄ
! RDENC0 053QSP Z BZ TF E
Low voltage power supply unit (230V) 低圧電源ﾕﾆｯﾄ
! RDENC0 051QSP Z BZ TF E
Low voltage power supply unit (100V) 低圧電源ﾕﾆｯﾄ
! 29 RDENU0 058 QSPZ BN LE E
High voltage power supply unit 高圧電源ﾕﾆｯﾄ
30 LHL DW1057 FCZZ AB DD C
Wire saddle(LWS-3S) ﾜｲﾔｰｻﾄﾞﾙ
31 DHA I-0588 QSPZ -BFGN C
AC switch harness [Missing parts code] AC ｽｲｯﾁﾊｰﾈｽ
1st lot
32 LFI X-0016 FCZZ AD DJ C
AC cord fixing (100V Series) AC ｺｰﾄﾞ押え
33 XEB S740P3 0000 AC DD C
Screw(4×30) ﾋﾞｽ
34 XEB S740P1 2000 AA DD C
Screw(4×12) ﾋﾞｽ
35 XWH S740-0 8100 AA DD C
Washer ﾋﾗﾜｯｼｬ
36 XWS S740-1 0000 AA DD C
Washer ﾊﾞﾈﾜｯｼｬ
37 LPL TM0349 QSZZ AS EQ C
Power supply fixing plate 電源取付板
38 NFA NP0020 QSPZ AP EQ B
P/S fan motor PS ﾌｧﾝﾓｰﾀｰ
39 XBP S730P3 0KS0 AC DD C
Screw(3×30KS) ﾋﾞｽ
42 XBP S730P0 8KS0 AB DD C
Screw(3×8KS) ﾋﾞｽ
45 LPL TM0369 QSZZ AG DS C
Delivery support angle 排紙保持ｱﾝｸﾞﾙ
46 XHB S740P1 0000 AA DD C
Screw(4×10) ﾋﾞｽ
47 LSU PP0133 FCPZ AC DJ C
PWB supporter 基板ｻﾎﾟｰﾀｰ
49 RCO RF0031 QSPZ AK DX C
Core ﾌｪﾗｲﾄｺｱ
50 LBN DJ0013 FCZ1 AE DJ C
Band 結束ﾊﾞﾝﾄﾞ
53 LHL DW1154 FCZZ AC DJ C
Wire saddle(LWS5S2W) ﾜｲﾔｰｻﾄﾞﾙ
56 LBN DJ0037 FCZ1 AA DJ C
Band (200V Series) 結束ﾊﾞﾝﾄﾞ
57 PTU BP0012 QSZZ AC DJ C
Tube(F5×20) (200V Series) ﾁｭｰﾌﾞ
59 RCO RF0004 QSZZ AF DS C
Core (200V Series) ﾌｪﾗｲﾄｺｱ
60 LBS HC0008 QSPZ AC DJ C
Edging(L=32) (200V Series) ｴｯｼﾞﾝｸﾞ
61 LPL TM0478 QSZZ AF DS C
AC Inlet fixing plate (200V Series) AC ｲﾝﾚｯﾄ取付板
62 XHS S730P0 6000 AB DD C
Screw(3×6) (200V Series) ﾋﾞｽ
63 XEB S730P1 2000 -ACDD C
Screw(3×12) ﾋﾞｽ
1st lot
64 XEB S730P1 0000 AC DD C
Screw(3×10) (200V Series) ﾋﾞｽ
45
