– 51 –
Update : 2009/10/16
V
2nd 給紙部 (2nd paper feed section)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
2 PCO VP0 070QSZ Z AD DJ D
Sensor cover ｾﾝｻｰｶﾊﾞｰ
4 CPW BF0 095QSE 3 AP EQ E
2nd cassette sensor PWB 2nd ｶｾｯﾄｾﾝｻｰ
基板
5 MLE VP0 063QSZ 1 AD DJ C
Upper limit detect actuator 上限検知
ｱｸﾁｭｴｰﾀｰ
6 MLE VP0 064QSZ Z AD DJ C
Paper detect actuator 紙検知ｱｸﾁｭｴｰﾀｰ
7 MLE VP0 062QSZ Z AC DJ C
P-IN detect actuator 入紙検知
ｱｸﾁｭｴｰﾀｰ
8 PCO VP0 064QSZ Z AD DJ D
Solenoid cover ｿﾚﾉｲﾄﾞｶﾊﾞｰ
9
RPLU-0 026 QSZ1 AR EQ B
Paper feed solenoid 給紙ｿﾚﾉｲﾄﾞ
RPLU-0 026 QSP1 1AREQ B
Paper feed solenoid 給紙ｿﾚﾉｲﾄﾞ
09/09
10 MAR MP0026 QSZZ AD DJ C
Solenoid arm ｿﾚﾉｲﾄﾞｱｰﾑ
11 MSP RC0209 QSZ1 AC DJ C
Solenoid spring ｿﾚﾉｲﾄﾞｽﾌﾟﾘﾝｸﾞ
13 NSF TZ0102 QSZZ AH DX C
2nd paper feed roller shaft 2nd 給紙ﾛｰﾗｰ軸
14 QSW -B0017 QSZZ AF DS B
Tray detect switch ﾄﾚｲ検知ｽｲｯﾁ
17 DHA I-0397 QSPZ AD DJ C
Cassette detect interface harness ｶｾｯﾄ検知中継
ﾊｰﾈｽ
18 NBR GC0100 FCZ1 AC DJ C
Bearing 6 ﾍﾞｱﾘﾝｸﾞ 6
19 MSP RD0389 QSZZ AC DJ C
Pick up roller pressure spring ﾋﾟｯｸｱｯﾌﾟﾛｰﾗｰ
加圧ｽﾌﾟﾘﾝｸﾞ
20 MAR MP0021 QSZZ AD DJ C
Pick up arm R ﾋﾟｯｸｱｯﾌﾟｱｰﾑ R
21 NGE RH0107 QSZZ AD DJ C
Paper feed gear(20T) 給紙ｷﾞﾔ
22 LPI N-0026 MCZZ AA DD C
Spring pin(φ2-8) ｽﾌﾟﾘﾝｸﾞﾋﾟﾝ
23 NRO LR0132 QSZ1 AR EQ C
Paper feed roller AND2 給紙ﾛｰﾗｰ AND2
24 MAR MP0019 QSZZ AD DJ C
Pick up arm F ﾋﾟｯｸｱｯﾌﾟｱｰﾑ F
26 NGE RH0990 FCZZ AB DJ C
Gear(16T) ｷﾞﾔ
27 NRO LR0133 QSZZ AM EG A
Pick up roller ﾋﾟｯｸｱｯﾌﾟﾛｰﾗｰ
29 DHA I-0394 QSPZ AD DJ C
Door open/close detect harness ﾄﾞｱ開閉検知
ﾊｰﾈｽ
30 MSP RD0204 QSZZ AC DJ C
Paper feed in detect actuator spring 入紙検知
ｱｸﾁｭｴｰﾀｰ
ｽﾌﾟﾘﾝｸﾞ
31 DHA I-0473 QSP1 AG DX C
Cassette sensor PWB harness ｶｾｯﾄｾﾝｻｰ基板
ﾊｰﾈｽ
