A6. COMMAND DESCRIPTION
A-19
Power Supply Unit
INSTRUCTION MANUAL
A
A6.3 Run Status
Commands CS
Run Status Check
This command requests the current power supply status.
Answers
NS
Stop
This answer is returned when the pump stops. Equivalent to the monitor mode/
STOP run status on the LCD display.
For a normal status, "00" is returned as the sub-command. If a warning has
occurred, the 2-character alarm code is returned as the sub-command.
NA
Acceleration
This answer is returned during pump acceleration. Equivalent to the monitor mode/
ACC. run status on the LCD display.
For a normal status, "00" is returned as the sub-command. If a warning has
occurred, the 2-character alarm code is returned as the sub-command.
NN
Normal rotation
This answer is returned during normal pump rotation. Equivalent to the monitor
mode/NORMAL run status on the LCD display.
For a normal status, "00" is returned as the sub-command. If a warning has
occurred, the 2-character alarm code is returned as the sub-command.
NB
Deceleration
This answer is returned during pump deceleration. Equivalent to the monitor mode/
BRAKE run status on the LCD display.
For a normal status, "00" is returned as the sub-command. If a warning has
occurred, the 2-character alarm code is returned as the sub-command.
FS
Failure-Stop
This answer is returned when the pump is stopped after a failure occurs. Equivalent
to the monitor mode/E-STOP run status on the LCD display.
The 2-character alarm code is returned as the sub-command.
FF
Failure-Free run
This answer is returned when the pump is free-running (neither accelerating nor
decelerating) after a failure occurs. Equivalent to the monitor mode/E-IDLE run
status on the LCD display.
The 2-character alarm code is returned as the sub-command.
FR
Failure-Regenerative braking
This answer is returned when the pump is regenerative braking after a failure
occurs. Equivalent to the monitor mode/E-BRAKE run status on the LCD display.
The 2-character alarm code is returned as the sub-command.
FB
Failure-Deceleration
This answer is returned when the pump is decelerating after a failure occurs.
Equivalent to the monitor mode/E-BRAKE run status on the LCD display.
The 2-character alarm code is returned as the sub-command.
Commands CF
Read alarm list
Reads the alarm that occurred for a designated alarm list number.
The alarm list numbers are equivalent to the sequence displayed on the LCD in the
LCD display alarm mode. To check all the current failures, the sub-command alarm
list number is increased sequentially from 01 until the answer CV is returned.
Answers
CA
Send alarm list
Returns the alarm code corresponding to the requested alarm list number. The
sub-command returns a 2-character alarm list number and a 2-character alarm
code.
CV
No alarm list
This answer is returned if no alarm corresponds to the requested alarm list number.
The sub-command returns a 2-character alarm list number.
