6.6 Software Operation
57
Power Supply Unit
INSTRUCTION MANUAL
6
(5) MENU MODE/SELF TEST
Mode Operation and LCD Display Description of Display
SELF
TEST
Select YES and press the SET key to
execute self-diagnosis of the magnetic
bearing sensor. If an abnormality is
discovered by self-diagnosis, alarm codes
81 to 85 occur. Refer to Table 7-5 for the
appropriate remedy. This function can be
used only when the pump is stopped.
SELECT SET
MENU
SELF TEST
SELF TEST
SENSOR CHECK
SELECT SET
SENSOR CHECK
CHECK SENSOR=NO
SENSOR CHECK
CHECK SENSOR=N
O
+ -
Press the or
key to select between
NO or YES.
To Next Page
