6.7 Remote-Control Connector
59
Power Supply Unit
INSTRUCTION MANUAL
6
Table 6-3 Remote-Control Signals (Default Settings)
(Note 1) "STOP" signal is prior to "START" signal.
(Note 2) It is possible to change movement by remote-control signal settings of settings mode.
(See Section 6.6 "Software Operation" (4).)
(Note 3) Don't connect any pins other than specified above.
(Note 4) See Table 7-6 "Table of Alarms" and Table 7-6 "Table of Alarms" about alarm and
warning.
(Note 5) One Reset signal is input each time the contacts close. Repeatedly short and open
the contacts to input multiple Reset signals. See section 7.5.3 for details about the
error-reset procedure.
(Note 6) Approximately 6 seconds is required for the remote control signal to turn ON after the
POWER switch is turned ON.
Classifi-
cation
Signals Pin No. Operation Electric spec.
Inputs
START
(15)
Starting operation on GND and short-
circuiting (Note 1)
Contact input
STOP
(16)
Stopping operation on GND and circuit
opening (Note 1) (Note 2)
RESET
(17)
Resetting operation on GND an short-
circuiting
LOW SPEED
(33)
Variable Speed Operation on GND and
short-circuiting
GND
(14)
Outputs
ROTATION
(29),
(4),
(30)
During rotation;
(29) - (30) : open → close (make contact)
( 4 ) - (30) : close → open (break contact)
Contact output
Contact capacity
(resistance load)
30 VDC 1 A
NORMAL
(25),
(2),
(26)
During normal rotation;
(25) - (26) : open → close (make contact)
( 2 ) - (26) : close → open (break contact)
ACCELERATION
(23),
(1),
(24)
During acceleration;
(23) - (24) : open → close (make contact)
( 1 ) - (24) : close → open (break contact)
BRAKE
(27),
(3),
(28)
During deceleration;
(27) - (28) : open → close (make contact)
( 3 ) - (28) : close → open (break contact)
REMOTE
(31),
(5),
(32)
Remote-controlled operation is available;
(31) - (32) : open → close (make contact)
( 5 ) - (32) : close → open (break contact)
(Note 2)
ALARM
(Note 4)
(21),
(20),
(22)
Against alarm;
(21) - (22) : open → close (make contact)
(20) - (22) : close → open (break contact)
(Note 2)
WARNING
(Note 4)
(12)
(11)
(13)
Against warning;
(12) - (13) : open → close (make contact)
(11) - (13) : close → open (break contact)
(Note 2)
