Original User Guide | Pedelec Shimano Steps E6000 Version 1 EN-15
3.2 Adjustingthesaddleheight
3.2.1 Determiningthecorrectsaddleheight
1. Sit on the pedelec and at the same time lean against a wall.
2. Turn the foot pedal on the opposite side to the wall to its lowest point.
3. Place your heel on the pedal. Your leg should be fully extended.
4. If your leg is not fully extended when your heel is
on the pedal, raise the saddle. Lower the saddle
if you cannot reach the pedal. The following
sections explain how to adjust the saddle height
on your bike. The seatpost can be fastened using
the saddle clamp bolt  3.2.2 Adjusting the
saddle height: Saddle clamp bolt(s)* Page EN-15 or
quick-release skewer  3.2.3 Adjusting the
saddle height: Quick-release skewer* Page EN-16.
WARNING
Seatpost marking
Theseatpostismarkedtoindicatehowfaryou
maypullitoutfromtheframe.Neverpullthe
seatpostfurtheroutthanthemarking.This could
cause it to bend or break, and cause you to fall.
For3. Extend leg
3.2.2 Adjustingthesaddleheight:Saddleclampbolt(s)*
1. Undo the saddle clamp bolt(s) by turning
it/them anticlockwise with an Allen key.
2. Move the seatpost into the right position.
3. Tighten the saddle clamp bolt(s) again
by turning it/them clockwise  8.
Torque settings Page EN-46.
4. Test the tightness of the saddle by trying
to move it.
For1. Loosen the saddle clamp bolt(s)
For3. Tighten the saddle clamp bolt(s)
*dependent on model
