Shimano STEPS E6000 - Battery Display During Charging

EN-42 Original User Guide | Pedelec Shimano Steps E6000 Version 1
5. The charger switches o once the battery is fully charged. The green
LED on the charger is continually on
. All ve LEDs on
the battery light continually. No LED ashes.
If the battery now stays on the charger, the charger regularly
checks whether the battery is still fully charged. The charger
LED starts to ash again. After checking and ascertaining
that the battery is full, the charger switches back to “light
continually”.
6. Remove the power cable from the socket after completing the charging
process.
7. Remove the charging cable from the battery charging socket.
8. Fold down the protective battery cap.
6.3.1.1Batterydisplayduringcharging
Display Description Batterychargelevel

5 LEDs light up and no LED ashes 100 – 97 %


4 LEDs light up and the 5th LED ashes 80 – 96 %


3 LEDs light up and the 4th LED ashes 60 – 79 %


2 LEDs light up and the 3rd LED ashes 40 – 59 %


1 LED lights up and the 2nd LED ashes 20 – 39 %

1 LED ashes 0 – 19 %
