EN-46 Original User Guide | Pedelec Shimano Steps E6000 Version 1
Screwxing Thread Tighteningtorque(Nm)
Pedal 9/16 40
Front axle nut General 25 – 30
Rear axle nut
General
35 – 40
Ahead stem angle adjustment M6 8 – 10
Ahead stem steerer tube M5 / M6 / M7 M5: 5 / M6: 10 / M7: 14
Saddle clamp bottom M5 / M6 / M8 M5: 5 / M6: 10 / M8: 20
Saddle clamp top M5 / M6 / M7
/ M8
M5: 5.5 / M6: 5.5 / M7: 14 / M8:
20
Rim brake shoe M6 10
Disc brake calliper, Shimano, IS and PM M6 6 – 8
Disc brake calliper, AVID, IS and PM M6 8 – 10
Disc brake calliper, Magura, IS and PM M6 6
Gear lever clamp M5 5
Brake lever clamp M5 Ref. manufacturer's spec.
Cassette xing ring N/A 30 – 40
Screw-on handlebar plugs M4 / M5 M4: 3 / M5: 5
Luggage rack M5 / M6 M5: 5 – 6 / M6: 8 – 10
7.2 Charger
Display Description Cause Remedy
The red
LED ashes
continuously.
There is a
charging fault.
Unplugthechargerfromthe
mainsimmediately.If the
problem reoccurs, a new
battery charger is required.
8. Torquesettings
DANGER
Onlyuseappropriatetoolstotightenscrewsandbolts.Observe
thespeciedtorquesetting.Thecomponentmanufacturer'storque
settingstakeprecedence(whereavailable). Failure to comply can
result in screws/bolts becoming loose, tearing away or fracturing. If
that happens while you are riding the bike, components may come
o and you could have a severe crash. If screws are overtightened,
components can also be damaged. Tighten all screws and bolts
that are relevant for safety with a torque wrench. This indicates the
corresponding torque in newton metres (Nm).
If no values are shown on the component or component manuals, use the
torque settings from the following table.
