3. Shimmer3 Platform Overview
This section provides an overview of the main components of the Shimmer3 platform. The scope and
level of detail provided here is aimed at the general Shimmer user and should be sufficient for
understanding the core concepts of the Shimmer3 platform. For more specific and detailed
information, please refer to the later sections of this document along with the additional user
guides, which are referred to throughout the document.
3.1. Components
Table 3-1 lists the key components of the Shimmer3 platform.
Feature
Purpose
Component/Capabilities
I/O
Capture of sensor and
user data.
Integrated
 3 Axis Low Noise Accelerometer array
 3 Axis Wide Range Accelerometer array
 3 Axis Gyroscopes (Angular Rate sensors)
 3 Axis Magnetic Sensor
 Relative Pressure Sensor (Altimeter)
 Temperature Sensor
 5 multi-coloured status LEDs
 Software-defined user button
Expansion
 7 channels of analog expansion
 UART, SPI, and I2C peripheral bus support
 18-position rugged external connector (Hirose ST60 series) for
charging, programming, flash data access, additional analog
channels and tethered sensor extensions.
 Keyed 16-signal micro-sized stacking connector for serial or analog
peripherals
 FFC-Type expansion header for alternative radio chipset,
coprocessor, or digital peripherals
 JTAG debugging mode on external connector
Processing
Control operating state.
Provide best signal
quality.
Operational alerts and
messages.
MSP430F5437A CPU
 16Kbyte RAM, 256Kbyte Flash
 Up to 24MHz
 DAC outputs
 12 bit A/D inputs
 Extremely low power during periods of inactivity
 Hi-tolerance clocking including .5ppm temperature compensated
crystal oscillator module.
Storage
No loss of data while
mobile, during network
outages or while
changing batteries.
microSD slot
 Up to 32GByte capacity
 Full-speed host transfer when docked (requires use of Shimmer
Dock).
 Soft-power control
Communication
Hi-reliability.
Standards-Based .
Mobility.
Class 2 Bluetooth Radio
 Roving Networks RN-42
 Soft-power control
Power
Long operating life.
Safe operation.
 Battery voltage monitoring
 450mAh Battery
 Smart charger
 Designed for EN 60601-1 Compliance
Table 3-1 Shimmer3 Mainboard Key Features
