63
P1.4
21
GPIO_INTERNAL
TBD
Input (IRQ)
P1.5
22
GPIO_EXTERNAL_RADIO_DD
TBD, RADIO EXP
Input (IRQ)
P1.6
23
USER_N
User Button
Input (IRQ)
P1.7
24
MPU_INT
Kinematics
Input(IRQ)
P2.0
25
GPIO_EXTERNAL1
Expansion
Input (IRQ)
P2.1
26
GPIO_EXTERNAL2
Expansion
Input (IRQ)
P2.2
27
RADIO_CTS
RADIO
Input (IRQ)
P2.3
28
DOCK
Input (IRQ)
P2.4
29
MAG_DRDY
Kinematics
Input (IRQ)
P2.5
32
MAG_INT1
Kinematics
Input (IRQ)
P2.6
33
CHG_STAT1
CHARGER
Input (IRQ)
P2.7
34
CHG_STAT2
CHARGER
Input (IRQ)
P3.0
35
SA_SCLK_R
Expansion
Output
P3.1
36
SB_SDA
USART B0
Output
P3.2
37
SB_SCL
USART B0
Input
P3.3
38
EXP_RESET_N
Expansion
Output
P3.4
39
SA_SIMO_TXD
USART A0
Output
P3.5
40
SA_SOMI_RXD
USART A0
Input
P3.6
41
RADIO_SCLK_R
RADIO EXP, USART A1
Output
P3.7
42
FLASH_SIMO
FLASH, USART B1
Output
P4.0
43
FLASH_CS_N_FLASH_DAT3
FLASH
Output
P4.1
44
SD_DETECT_N
FLASH
Input
P4.2
45
SW_FLASH
FLASH
Output
P4.3
46
SW_BT
RADIO
Output
P4.4
47
BT_RESET_N
RADIO
Output
P4.5
48
BT_FACTORY
RADIO
Output
P4.6
52
SW_TCXO
TCXO
Output
P4.7
53
TCXO_CLK_R
TCXO
Input (Clock)
P5.4
54
FLASH_SOMI
FLASH
Input
P5.5
55
FLASH_SCLK_R
FLASH
Output
P5.6
56
RADIO_TXD_SIMO
RADIO, RADIO EXP
Output
P5.7
57
RADIO_RXD_SOMI
RADIO, RADIO EXP
Input
P7.2
58
LED_RD
LED
Output
P7.3
59
LED_GR
LED
Output
P8.0
60
LED_YE
LED
Output
P8.1
61
RADIO_CS_N
RADIO EXP
Output
P8.2
62
RADIO_RESET_N
RADIO EXP
Output
P8.3
63
SW_RADIO
RADIO EXP
Output
P8.4
64
NOT ROUTED
P8.5
65
NOT ROUTED
P8.6
66
SW_ACCCEL
Kinematics
Output
P6.0
77
DETECT_N
FLASH
Output
P6.1
78
SEL_ADC
Expansion
Output
P6.2
79
BATTERY
ADC
Analogue Input
P6.3
80
ACCEL_X
Low Noise Accel
Analogue Input
P6.4
1
ACCEL_Y
Low Noise Accel
Analogue Input
P6.5
2
ACCEL_Z
Low Noise Accel
Analogue Input
P6.6
3
ADC6_FLASHDAT2
Ext GPIO, ADC
Analogue Input
P6.7
4
ADC7_FLASHDAT1
Ext GPIO, ADC
Analogue Input
P7.4
5
ADC12
ADC
Analogue Input
P7.5
6
ADC13
ADC
Analogue Input
P7.6
7
ADC14
ADC
Analogue Input
P7.7
8
ADC15_RADIO_DC
ADC, RADIO EXP
Analogue Input
