Features
Configurable Coverage
• Steerable Coverage™ delivers precise pickup for up to 8 independent lobes
•
IntelliMix
®
DSP Suite provides fast-acting automatic mixing, echo reduction, and channel equalization
Software Control
• Intuitive software interface provides comprehensive microphone and pattern control
• Includes templates to speed initial set-up and 10 customizable presets to import or export configurations between multiple microphones
Network Connectivity
• Discrete audio channels for each lobe and an automix channel are delivered over a single network cable
• Dante™ digital audio coexists safely on the same network as IT and control data, or can be configured to use a dedicated network
• Control strings available for third-party preset controllers including Crestron and AMX
Professional Design
• Sleek industrial design blends with contemporary board rooms and meeting spaces
• Seamless flush-mount with standard ceiling tiles
• Available in white, black, and aluminum finishes (detachable grille can be custom painted)
System Overview
① Dante audio, power, and control
Each array microphone connects to the network over a single network cable, which carries Dante™ audio, Power over Ethernet (PoE), and control information
to adjust coverage, audio levels, and processing.
② Analog audio (microphone to network)
Analog equipment, such as a wireless microphone system or a gooseneck microphone on a podium, connects to the Dante™ audio network through a Shure
Network Interface (model ANI4IN) for a completely networked conferencing system.
③ Far-end audio (network to loudspeakers)
Dante™ -enabled loudspeakers and amplifiers connect directly to a network switch. Analog loudspeakers and amplifiers connect through a Shure Network In-
terface (model ANI4OUT), which converts Dante™ audio channels into analog signals, delivered through 4 discrete XLR or block connector outputs.
④ Device control and Dante™ audio
Shure IncorporatedMXA910 Ceiling Array Microphone
2017/10/182/57
