Ceiling Grid Runner
Rubber Pad
Array Microphone
Installation
1. Remove the tile from the ceiling grid where the array microphone will be installed.
2. Run the Ethernet cable above the ceiling grid and through the opening in the ceiling.
Note: An optional junction box accessory (model A910-JB) mounts on the microphone to directly connect conduit.
3. Plug the Ethernet cable into the array microphone output.
4. Install the microphone into the ceiling grid.
Shure IncorporatedMXA910 Ceiling Array Microphone
2017/10/1818/57
