IP Ports and Protocols
Factory DefaultDescriptionProtocolTCP/UDPPort
ClosedRequired for firmware updates (otherwise closed)FTPtcp21
ClosedNot supportedSSHtcp22
ClosedStandard console interfaceTelnettcp23
OpenDynamic Host Configuration ProtocolDHCPudp68
OpenRequired to launch embedded web serverHTTPtcp80*
OpenRequired for inter-device communicationSLP†
tcp/udp
427
ClosedNot supportedHTTPStcp443
ClosedNot supportedSNMPtcp161
ClosedNot supportedSNMPtcp162
OpenRequired for 3rd party control stringsASCIItcp2202
OpenRequired for device discoverymDNS†
udp
5353
OpenRequired for inter-device communicationSDT†
udp
5568
PasswordDebug console interfaceTelnettcp8023
OpenRequired for web applicationHTMLtcp8180*
OpenRequired for inter-device communicationMultcast SLP†
udp
8427
OpenRequired for Shure firmware updateTelnettcp64000
DescriptionProtocolTCP/UDPPort
Used by DanteSNMPudp162
Dante clocking
PTP†
udp[319-320]*
Required for packet bridgeCustomudp2203
Dante audioDanteudp
4321,
14336-14600
Dante audio routingDanteudp
[4440, 4444,
4455]*
Used by Dante
mDNS†
udp5353
Dante Control and MonitoringDanteudp
[8700-8706,
8800]*
Dante ControllerDanteudp8751
Used by DanteDanteudp16000-65536
0 1
Using a Third-Party Control System
Control Systems
The microphone receives logic commands over the network. Many parameters controlled through the web application can be controlled through a third party
control system, using the appropriate command string.
Common applications:
• Mute
• LED color and behavior
• Loading presets
• Adjusting levels
0
*These ports must be open on the PC or control system to access the device through a firewall.
1
†These protocols require multicast. Ensure multicast has been correctly configured for your network.
