Shure Microflex Advance MXA910 - Digital Signal Processing

Built-in Digital Signal Processing
Equalizer (4-band Parametric), Mute, Gain (140 dB range)Per Channel
IntelliMix® Automatic mixing, Echo ReductionSystem
Intelligibility Scale
Equivalent acoustic performance, compared to a cardioid gooseneck microphone (environment dependent)
Cardioid distance multiplied by 1.6
3
Networking
Cable Requirements
Cat 5e or higher (shielded cable recommended)
4,000 Hz
2,500 Hz
1,500 Hz
1,000 Hz
Wide Medium Narrow
Polar Pattern
20
15
10
5
0
-30
-25
-20
-15
-10
-5
dB
Hz
20 100 1k 10k 20k
Frequency Response
Lobe Sensitivity
The edge of the blue coverage area for each channel in the web application represents where the sensitivity reaches -6 dB. Understanding how lobe sensitivity
is displayed helps to:
3
[1] 1 Pa=94 dB SPL
