B = Distance between cardioid microphone and talker
In this example, the acoustic performance of the array microphone mounted (A) feet from the talker matches the cardioid gooseneck microphone placed at a
distance of (B) feet from the talker.
FyreWrap
®
Fire Protective Wrap System Installation
The FyreWrap
®
fire protective wrap system included with the Microflex
®
Advance™ MXA910 ceiling array microphone must be installed to meet the UL 2043
plenum rating (suitable for air handling spaces).
Installation
1. Make sure the microphone surface is clean to ensure proper adhesion
2. Remove the paper backing from the 4 adhesive pads on the fire wrap system
3. Align the fire wrap system over the microphone and secure it by applying gentle pressure over the adhesive pads
Note: make sure to leave enough space to install the Ethernet cable and safety tether (if required).
Shure IncorporatedMXA910 Ceiling Array Microphone
15/572017/10/18
