8.5.1 Temperature range
This resource indicates the minimum and maximum permitted values for the tempera‐
ture of the DSL motor feedback system given in the product data sheet.
Direct read access to temperature range returns the defining values:
Table 74: Temperature range defining values
Defining value Offset Value
RID 0C0h
Resource name 0 "TEMPRNG"
Data size 1 4
Read access level 2 0
Write access level 3 15
Time overrun 4 70
Data type 5 08h – 16 bit, with sign
Mandatory yes
The temperature range values are stored as signed 16 bit values in the form of two's
complements. The temperature value units are tenths of degrees Celsius (0.1 °C).
Examples of temperature range values:
Table 75: Examples of temperature ranges
Temperature Resource value (bin.) Resource value (hex.)
20.0 °C 0000 0000 1100 1000b 00C8h
115.0 °C 0000 0100 0111 1110b 047Eh
-40.0 °C 1111 1110 0111 0000b FE70h
The temperature range values are given in the following format:
Table 76: Temperature range definition
Byte Value Description
3/2 -2730 to 10000 Maximum permitted encoder temperature in 0.1 °C
1/0 -2730 to 10000 Minimum permitted encoder temperature in 0.1 °C
By accessing offset basis, only one of two temperature range values can be given.
Table 77: Selection of the temperature range offset
Offset value Length of the message Return values
0000h 4 Temperature range minimum and maximum val‐
ues
0000h 2 Minimum temperature
0002h 2 Maximum temperature
Table 78: Reading the temperature range
Transaction
Register
PC_BUFFER0 PC_BUFFER1 PC_BUFFER2 PC_BUFFER3 PC_BUFFER4 PC_BUFFER5 PC_BUFFER6 PC_BUFFER7 PC_ADD_H PC_ADD_L PC_OFF_H PC_OFF_L PC_CTRL
Write 58 C0 00 00 01
Wait for FREL = 1
Read Min. temp. Max.
temp.
