"Short message" transactions are generated if operations are carried out with remote

registers (DSL Slave). Generally, FRES (in the EVENT_S register) must be set after a

transaction is started. Only then will PC_DATA contain valid information.

R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0

"Short message" Parameters Channel data

Bit 7 Bit 0

Bit 7-0 "Short message" Parameters Channel data

8 bit value of the requested remote register.

6.3.24 Fast position error counter

The ACC_ERR_CNT register returns the count of transmitted fast position values with

consecutive transmission errors. The value is clamped to a maximum of 31 (1Fh).

With a writing access the error threshold for the test signal acc_thr_err can be set.

This value is also clamped to a maximum of 31 (1Fh). If the count of transmitted fast

position values with consecutive transmission errors exceeds this threshold

acc_thr_err will be set to ‘1’.

X-0 X-0 X-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

- - - CNT4 CNT3 CNT2 CNT1 CNT0

Bit 7 Bit 0

Bit 7-5 Not implemented: Read as "0".

Bit 4-0

CNT4:CNT0: Position error count/threshold for acc_thr_err

Read: 5 bit value of count of transmitted fast position values with consecutive transmis‐

sion errors

Write: 5 bit value for threshold of acc_thr_err

6.3.25 Fast position acceleration boundary

The MAXACC register allows setting an acceleration threshold for a given application.

This threshold is used by the fast position estimator to clamp the acceleration of the

estimated position during communication or sensor failures of the fast position chan‐

nel.

W-1 W-1 W-1 W-1 W-1 W-1 W-1 W-1

RES1 RES0 MNT5 MNT4 MNT3 MNT2 MNT1 MNT0

Bit 7 Bit 0

Bit 7-6 RES1:RES0: Resolution of fast position acceleration boundary

Bit 5-0

MNT5:MNT0: Mantissa of fast position acceleration boundary
