SICK HIPERFACE DSL - Page 92

Defining value Offset Value
Data size 1 2
Read access level 2 0
Write access level 3 15
Time overrun 4 75
Data type 5 00h – node indicator
Mandatory yes
Indirect read access to the monitoring node returns information on linked nodes (see
table 47).
8.3.4 Administration node
The administration node contains indicators to all resources associated with adminis‐
tration in the motor feedback system (e.g. reset, determining access level).
Direct read access to the administration node returns the defining values:
Table 51: Administration node defining values.
Defining value Offset Value
RID 003h
Resource name 0 "ADMIN"
Data size 1 2
Read access level 2 0
Write access level 3 15
Time overrun 4 75
Data type 5 00h – node indicator
Mandatory yes
Indirect read access to the administration node returns information on linked nodes
(see table 47).
8.3.5 Counter node
The counter node contains indicators to all resources associated with the user- defined
counter.
Direct read access to the counter node returns the defining values:
Table 52: Counter node defining values.
Defining value Offset Value
RID 004h
Resource name 0 "COUNTER"
Data size 1 2
Read access level 2 0
Write access level 3 15
Time overrun 4 75
Data type 5 00h – node indicator
Mandatory yes
Indirect read access to the counter node returns information on linked nodes (see
table 47).
