Device configuration
You can configure the device in two ways:
•
Interactively using SOPASET. This section describes the interactive configuration.
•
Using configuration telegrams, see "Communicating data via telegrams", page 20.
Interactive configuration with SOPAS ET
All configurable parameters of the device are collected together in a corresponding
device description (.sdd file) for SOPASET. You can access these parameters via the
project tree for the device description.
A content-sensitive explanation of each of the parameters is available directly next to
the parameter via the ? button or in the online help (F1 key). The Parameter Info display
window lists the valid range of values and the default setting (right-click when the
pointer is located over the parameter).
NOTE
Software access to the device is protected by user levels and passwords. After success‐
fully configuring the device, you should change the passwords so they can fulfill their
protective function.
Table 9: Passwords
User levels Password
Maintenance
main
Authorized Client
client
Service
servicelevel
Operator –
NOTE
Change the passwords during initial commissioning to protect your device.
A higher user level can change the password of a lower user level.
Use the project tree in SOPAS ET to configure the necessary parameters for your
application.
NOTICE
Loss of configuration data in the connected device
1. Do not switch off the voltage supply during the configuration of the device. Other‐
wise all parameters not yet saved permanently will be lost.
1. In the Options menu, select the Log into device command and log in as an Authorized
customer using the password client.
2. Configure the device for the required application using the parameters in
SOPASET. Help on using the program user interface as well as for the different
options can be found in SOPASET.
Resetting the configuration
NOTE
To reset the device to the delivery condition, use the Factory defaults option in SOPASET.
7.5 Connecting and performing a test measurement
Use the graphic scan view in SOPASET to verify the generated measured values and
the measuring range online.
