SICK SLG-2 User Manual

Figure 8: Minimum distance SLG-2 to reflective materials
R T
Figure 9: Distance to reflective objects
Avoiding interference with other SLG-2 light grids
When several SLG-2s are mounted close to one another, there is a risk of mutual
interference. Therefore, when mounting two SLG-2s close to one another, their light
beams should be oriented in opposite directions.
R
T
T R
Figure 10: Light grid installed in opposite directions R = Receiver; T = Transmitter (sender)
4 MOUNTING
18
O P E R A T I N G I N S T R U C T I O N S | SLG-2 8026014/2021-06-10 | SICK
Subject to change without notice
