Figure 29: Possible pin 2 configurations
7.7.1 Smart Task via IO-Link
Table 6: Smart Task via IO-Link with associated index
IO-Link Index Object name Description
121 Pin 2 configuration Configuration of pin 2 output or
input function
481 Q
L
/ Q
int
(PDin) Outputs the Q
L
/ Q
int
states.
1081 Input selector 1 Selection of zone values Q
int
1-4
or an external input signal Ext.-
input 1 as logical input signal
1082 Input selector 2 Selection of zone values Q
int
1-4
or an external input signal Ext.-
input 1 as logical input signal
1083 Logic 1 AND or OR logic to the possible
input signals Q
int
1-4 or Ext.-input
1
1084 Logic 2 AND or OR logic to the possible
input signals Q
int
1-4 or Ext.-input
1
1085 Timer 1 mode Delay modes adjustable: T-On
Delay, T-Off Delay, ...
1086 Timer 2 mode Delay modes adjustable: T-On
Delay, T-Off Delay, ...
1087 Time 1 setup Delay values in ms can be set
1088 Time 2 setup Delay values in ms can be set
1089 Inverter 1 Inverts the logic state of the
Timer 1 output signal
1090 Inverter 2 Inverts the logic state of the
Timer 2 output signal
1093 Inverter Ext.input Inverts the external input signal
OPERATION 7
8026014/2021-06-10 | SICK O P E R A T I N G I N S T R U C T I O N S | SLG-2
37
Subject to change without notice
