Timer function Deactivated
Switch-on delay
Switch-off delay
Switch-on and -off delay
Pulse (One Shot)
Inverter
✓
Switching signal Q
L1
Switching output
Switching signal Q
L2
Switching output
11.1 Resolution
To determine the resolution, 3 essential parameters have to be distinguished:
MDO: Minimum detectable object = minimum object size
MOL: Minimum object length
MOW: Minimum object width (only relevant in cross-beam mode)
The minimum object size differs between parallel-beam mode and cross-beam mode.
Description, chapter 3.2.4.
11.1.1 Minimum object size (MDO)
Parallel operation
Table 28: MDO in parallel-beam mode
Beam separation Minimum object size (MDO)
10 mm 15 mm
25 mm 30 mm
50 mm 55 mm
Cross-beam mode
A description of cross-beam mode can be found in chapter 3.2.4.
In cross-beam mode, the MDO depends on the beam separation, the cross-beam
option and the object position between the sender and receiver. The following graphic
serves for a better understanding:
11 TECHNICAL DATA
54
O P E R A T I N G I N S T R U C T I O N S | SLG-2 8026014/2021-06-10 | SICK
Subject to change without notice
