Sender
11.7 (0.46)
169
(6.65) 4.6
(0.18)
SenderReceiver
5.6
(0.22)
9
(0.35)
1 (0.04)
3.8 (0.15)
24.1 (0.95)
11.8
(0.47)
1
2
3
4
5
A
B
L
RM
Figure 41: SLG-2 Slim dimensional drawing
1
First light beam
2
Last light beam
3
Beam separation d
c
4
Detection height
5
Cable with male connector
TECHNICAL DATA 11
