SICK UM18-2 Pro User Manual

8014865/ZUJ3/2018-11-29 • © SICK AG • Subject to change without notice 47
Technical data
UM18-212 UM18-218
200
(7.87)
300
(11.81)
300
(11.81)
200
(7.87)
100
(3.94)
100
(3.94)
0
Detection area in mm (inch)
3
4
5
2
1
0
100
(3.94)
300
(11.81)
200
(7.87)
400
(15.75)
500
(19.69)
600
(23.62)
Detection area in mm (inch)
500
(19.69)
500
(19.69)
250
(9.84)
250
(9.84)
0
Detection area in mm (inch)
3
4
5
2
1
0
500
(19.69)
250
(9.84)
750
(29.53)
1,000
(39.37)
1,250
(49.21)
1,500
(59.06)
Detection area in mm (inch)
Fig. 16: "UM18-212" detection zone
1 Detection zone depends on reection characteristics,
size, and alignment of the object
2 Limiting range
3 Operating range
4 Example object: aligned plate 500 mm x 500 mm
5 Example object: round bar with diameter 10 mm
Fig. 17: "UM18-218" detection zone
1 Detection zone depends on reection characteristics,
size, and alignment of the object
2 Limiting range
3 Operating range
4 Example object: aligned plate 500 mm x 500 mm
5 Example object: round bar with diameter 10 mm
