Tabela 30: CC
H
D
3
NPN
PNP
4
H, PNP: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
D, PNP: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
H, NPN: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
D, NPN: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
45.2 WL34-Rxxx
U
B
20 V ... 250 V CA/CC, ver "Dados técnicos", página 54
Tabela 31: CA/CC
WL34-R2x0
1 L1
2 N
3 relé
4 relé
5 relé
1 2 3 4 5
0,14 ... 1,5 mm
2
INSTALAÇÃO ELÉTRICA 45
8009201.11O1 | SICK
