20 610.40 064.01 Siemens AG
3.2 Features
3.2.1 General information
The technical data of the drive is stated on the type plate.
Dimensions can be taken from the dimensional sketches in the relevant planning guide
or the DP tool "CAD-Creator".
Comply with permissible torques, make a current limitation on the servo
frequency converter if necessary.
The dimensional sheets of the DP tool "CAD-Creator" and the "Three-phase
servomotors" operating instructions contain additional technical values.
3.2.2 Gears
3.2.2.1 Worm gear
Transport temperature -20 °C to +40 °C (-4 °F to 104 °F)
Storage temperature 0 °C to +40 °C (32 °F to 104 °F)
Ambient temperatures -15 °C to +40 °C (5 °F to 104 °F)
otherwise the rated data are reduced
to 50 °C conversion factor 0,92
to 60 °C conversion factor 0,82
Installation altitude ≤up to 1000 m a.s.l,
2000 m conversion factor 0,94
2500 m conversion factor 0,9
Weight Refer to the type plate
Degree of protection as per EN 60-529 IP 65
Sound pressure level as per EN 60 034-9 approx. 75 dB(A)
Vibration severity grade as per EN 60 034-14 Grade N
True running, coaxiality, axial run-out devia-
tion as per IEC 60 072-1
Tolerance N
NOTE
The corresponding gear size can be seen in the second item of the gear type (see
type plate, fig. 7) or the second item of the first block of the order option.
Lubricant see rating plate
Oil filling quantity see rating plate
Bleeding:
- gear size 0 (mounting positions 2 and 5)
- gear sizes 1 to 4
- valve open
- valve lockable
Transport lifting tackle without

Siemens 1FK7 Series Specifications

General

Product type	Synchronous motor
Encoder	Incremental encoder, absolute encoder
Cooling method	Natural cooling, forced-air cooling
Degree of protection	IP64, IP65
Speed range	Up to 9000 rpm
Feedback system	Encoder or resolver
