General technical data
11.5 Dimension drawings
3RW44 soft starters
Manual, 03/2017, NEB535219502000/RS-AB/008
285
3RW44 5
3RW44 6
a
76 mm (3 in)
85 mm (3.35 in)
b 40 mm (1.6 in) 50 mm (1.97 in)
c
14 mm (0.6 in)
14 mm (0.6 in)
d
20 mm (0.8 in)
-
e
15.5 mm (0.7 in)
-
f
638.5 mm (25.2 in)
667 mm (26.3 in)
g
590 mm (9.45 in)
660 mm (26 in)
h
-
160 mm (6.3 in)
i
44 mm (1.8 in)
37.5 mm (1.48 in)
k
470mm (18 in)
535 mm (21 in)
l
510 mm (20 in)
576 mm (22.7 in)
m
16.5 mm (0.7 in)
16.5 mm (0.7 in)
n
105 mm (4.1 in)
103 mm (4.06 in)
o
253 mm (10 in)
251 mm (9.88 in)
p
623 mm (24.6 in)
693 mm (27.3 in)
q
-
43.5 mm (1.71 in)
r
-
40 mm (1.6 in)
s
-
20 mm (0.78 in)
t
249 mm (9.8 in)
249 mm (9.8 in)
u
162 mm (6.4 in)
162 mm (6.4 in)
v
152 mm (5.9 in)
151.4 mm (5.96 in)
w
-
123 mm (4.84 in)
ad 290 mm 290 mm
Weight
50.0 kg
78.0 kg
