Product description
Application Module FM 458-1 DP - User Manual 2-5
A5E01078222-02 Edition 03.2009
Binary inputs
PROFIBUS DP
RS232
interface
X201
LE bus
X121
K bus
X102
P bus
X101
Acknowledge button
X10
(MMC)
X1
X3
X2
S1
P bus
Slot for the program
memory modules
11 x LED
INTF
IF
UF
MF
CF
TF
RUN
STOP
EXTF
BUSF
Fig. 2-2 Mechanical design of the FM 458-1 DP application module
