Product description
Application Module FM 458-1 DP - User Manual 2-15
A5E01078222-02 Edition 03.2009
2.1.8 Technical data
Application module FM 458-1 DP 6DD1607-0AA1 / 6DD1607-0AA2
Usable MMC-Cards: 2, 4 or 8 MB
RS232 interface (V.24)
 Service protocol
 Data transfer rate
 DUST1
 19.2 kbaud
Number 8
Electrical isolation No (only via optional IF modules)
Input voltage
 permissible range
 nominal voltage
 for a 0 signal
 for a 1 signal
 -1 V to +33 V
 24 V
 -1 V to +6 V or open-circuit inputs
 +13.5 V to +33 V
Input current
 for a 0 signal, typical
 for a 1 signal, typical
 0 mA
 3 mA
Delay time per channel, max. 100 µs
Data transfer rate max. 12 Mbaud
Nominal voltages at 25 C
Typical current drain
(typical = 2/3 max.)
+5 V 2.2 A / 1.5 A
Battery +3.4V 15 µA
Power loss, typical 11 W / 7.5 W
ambient temperature
max. 40 C
Assignment, slots 1
Dimensions W x H x D [mm] 260 x 197 x 20.32
Weight 1.0 kg
Order No.
Program memory
Serial service
interface (X1)
Binary inputs (X2)
PROFIBUS DP
interface (X3)
Voltage, currents
Power loss
ambient
temperature
Dimensions
