Product description
2-8 Application Module FM 458-1 DP - User Manual
A5E01078222-02 Edition 03.2009
2.1.4 Supplementary components
Component Designation Order No.
Program memory
 MMC Program memory module, 2 Mbyte
 MMC Program memory module, 4 Mbyte
 MMC Program memory module, 8 Mbyte
MMC
 6ES7953-8LL00-0AA0
 6ES7953-8LM00-0AA0
 6ES7953-8LP10-0AA0
PROFIBUS bus cable with PROFIBUS bus terminal
with integrated terminating resistors and plug-in
cable
Refer to Siemens, Industrial
Communications and Field
Devices, Catalog IK PI 2000
e.g. 6GK1500-0AA00
PROFIBUS bus cable with PROFIBUS bus coupler
with integrated terminating resistors
(up to 12 Mbit/s)
Refer to Siemens, Industrial
Communications and Field
Devices, Catalog IK PI 2000
e.g. 6ES7972-0BB10-0XA0
6ES7972-0BB40-0XA0
Cable for PC (9-pin/9-pin)
to connect to an FM 458-1 DP
SC57 6DD1684-0FH0
Cable for FM 458-1 DP (9-pin/10-pin)
to connect an SBxx or SU12 to the binary inputs of
the FM 458-1 DP, length: 2m
SC64 6DD1684-0GE0
Interface module
10 pin direct connection (1:1 converter)
SU12 6DD1681-0AJ1
Interface module
Binary inputs and outputs
SB10 6DD1681-0AE2
Interface module
Binary inputs 24/48 V
SB61 6DD1681-0EB3
power supply connector for Interface module SB10,
SB61
SM11 6DD1680-0BB0
Table 2-2 Supplementary components for the FM 458-1 DP application module
For further informations about the interface modules see documentation
“SIMADYN D Hardware”
