Product User Manual
Operating Instructions, Version AE 12/2009, A5E01454341C
45
GenIV Specifications
4
4.1 System Specifications
Parameter Rating
Input Line Voltage 2.4, 3.0, 3.3, 4.16, 4.8, 6.0, 6.3, 6.6, 6.9, 7.2, 8.4, 10, 11, 12, 12.47, 13.2, or 13.8kV; 3 phase;
±10% / -5%
Input Frequency 50 or 60 Hz ±5%
Input Power Factor > 0.95 above 10% load
Input Harmonics <= 5% TDD with ambient THDv <= 2%
Copper Wound Transformer: 98% Transformer, 99% Converter, > 96,5% Total VFD Efficiency
Aluminium Wound Transformer: 97,5% Transformer, 99% Converter, > 96% Total VFD
Output Horsepower,
Frame Sizes
200-1100 (9 Cell - Size 1), 800-2250 (9 Cell - Size 2),
300 - 3500 (15 Cell), 600-6000 (24 Cell)
9 Cell 15 Cell 24 Cell
2300 V 6000 V 10000 V
3000 V 6600 V 11000 V
3300 V
4000 V
4160 V
Output Voltage
Output HVF < 0.03
Output dv/dt < 3000 V/µS
Output Current 40, 70, 100, 140 A, 200 A, 260 A Cell Frame Sizes
Overload Capacity 150% 1 minute / 10 minute (Ambient temperature <40°C)
Output Frequency & Drift
1
0.5 - 330 Hz, ± 0.5%
Output Torque 10 - 167 Hz rated torque (2 Quadrant)
Design Life 20 years
Auxiliary Voltage 380 - 400 - 415V, 50 Hz; 460 - 480V, 60 Hz; 3 phase
2)
Enclosure Type NEMA 1 Ventilated
Degree of Protection IP 31
Ambient Temperature 0 - 40 °C (max. 50 °C, derating starts from 40 °C on)
Humidity 95% non-condensing
Altitude 0 - 3300 ft. without derating
Cooling Ventilated, forced air-cooled with integrated fans
1) For high speed projects (> 300 Hz), consult Siemens concerning trade sanctions
2) Consult factory for availability of auxiliary voltages other than shown
