Product Description
5.2 Cabinet Outlines
Product User Manual
52 Operating Instructions, Version AE 12/2009, A5E01454341C
5.2 Cabinet Outlines
The cabinet configurations of the GenIV Perfect Harmony drives vary, depending upon the
project requirements for input and output voltage, and output power and amperage. The
GenIV, in its core configuration, consists of a single cabinet with multiple sections. Single
cabinet units are shipped with their blower cage(s) removed. The various sections are
described below:
● Transformer section
● Cell section
● Input/output section
● Control section
● Control wire way
● Blower #1 (and #2 with redundant option)
GenIV is offered in various core configurations, dependent upon the number of cells and
power cell type amperage.
Core configurations are listed in the following table
Table 5- 1 GenIV Core Configurations:
Cells in Drive
(without Redundancy)
Output Voltage
Available L-L
(with O-M)
Hp Range Power Cell Types (Continuous
Current Rating)
9 4000 V (4160 V) 200-1100 40, 70, 100, 140
9 4000 V (4160 V) 800-2250 40, 70, 100, 140, 200, 260
15 6600 V (6600 V) 300-3500 40, 70, 100, 140, 200, 260
24 10000 V (11000 V) 600-6000 40, 70, 100, 140, 200, 260
