Product Description
5.3 Cabinet Details
Product User Manual
Operating Instructions, Version AE 12/2009, A5E01454341C
71
Table 5- 9 Cell Section Components 6600 V, 40-260 Amp
Component Label Part Description
A1, A2, A3, A4, A5, B1, B2, B3, B4, B5, C1, C2, C3, C4, C5 GenIV Power Cells (40, 70, 100, 140, 200, or 260 Amp
types)
BPKA1, BPKA2, BPKA3, BPKA4, BPKA5, BPKB1, BPKB2,
BPKB3, BPKB4, BPKB5, BPKC1, BPKC2, BPKC3, BPKC4,
BPKC5
Mechanical Cell Bypass Contactors (Optional)
FA1A, FA1C, FA2A, FA2C, FA3A, FA3C, FA4A, FA4C,
FA5A, FA5C, FB1A, FB1C, FB2A, FB2C, FB3A, FB3C,
FB4A, FB4C, FB5A, FB5C, FC1A, FC1C, FC2A, FC2C,
FC3A, FC3C, FC4A, FC4C, FC5A, FC5C
Power Cell A and C Phase Input Fuses
K2 Mechanical Key Interlock (Optional)
Table 5- 10 Cell Section Components 10000 V, 40-260 Amp
Component Label Part Description
A1, A2, A3, A4, A5, A6, A7, A8,
B1, B2, B3, B4, B5, B6, B7, B8,
C1, C2, C3, C4, C5, C6, C7, C8
GenIV Power Cells (40, 70, 100, 140, 200, or 260 Amp
types)
BPKA1, BPKA2, BPKA3, BPKA4, BPKA5, BPKA6, BPKA7,
BPKA8,
BPKB1, BPKB2, BPKB3, BPKB4, BPKB5, BPKB6, BPKB7,
BPKB8,
BPKC1, BPKC2, BPKC3, BPKC4, , BPKC5, BPKC6,
BPKC7, BPKC8
Mechanical Cell Bypass Contactors (Optional)
FA1A, FA1C, FA2A, FA2C, FA3A, FA3C, FA4A, FA4C,
FA5A, FA5C, FA6A, FA6C, FA7A, FA7C, FA8C, FB1A,
FB1C, FB2A, FB2C, FB3A, FB3C, FB4A, FB4C, FB5A,
FB5C, FB6A, FB6C, FB7A, FB7C, FB8A, FB8C, FC1A,
FC1C, FC2A, FC2C, FC3A, FC3C, FC4A, FC4C, FC5A,
FC5C, FC6A, FC6C, FC7A, FC7C, FC8A, FC8C
Power Cell A and C Phase Input Fuses
K2 Mechanical Key Interlock (Optional)
Note
The core GenIV drive does not include medium voltage input switchgear. The K2 mechanical
interlock key must be coordinated with the input voltage switchgear.
