5.2 Cabinet Outlines
Product User Manual
Operating Instructions, Version AE 12/2009, A5E01454341C
53
5.2.1 9 cell, 4160 V Output, 200-1100 Hp
Figure " GenIV 4160 V Output 200 - 1100 Hp General Arrangement" details the GenIV
4160 V output 200 - 1100 Hp drive, and Figure "GenIV 4160 V Output 200 - 220 Hp,
Sectional View" points out each core section. The default color of the enclosure is ASA 61
Gray.
5HPRYDEOHSODWHIRU
UHGXQGDQWEORZHU
%RWWRP$FFHVV
3ODWHV
7RS$FFHVV
3ODWHV
Figure 5-1 GenIV 4160 V Output 200-1100 Hp General Arrangement
