Product Description
5.3 Cabinet Details
Product User Manual
Operating Instructions, Version AE 12/2009, A5E01454341C
83
The four components comprising NXG II Control are SCB, DCR, CPS, and IOB. The
components are fully detailed in the companion manual,
NXG Control Manual
A1A19001588.
Analog and Digital Input/Output
The input/output breakout (IOB) contains a finite amount of hard-wired I/O. Some of these
signals are dedicated for use within the drive (refer to Tables "Nine Cell, GenIV, Core
Hardwired I/O Assignments"). The remaining SPARE I/O can be used in agreement with the
Siemens project engineer for customer related signalization using the SOP.
Table 5- 13 Analog and Digital Input/Output
Signal Type Quantity Core Configuration Custom Options
Digital Inputs 20 120 VAC
1
a) Customer powered
2
b) 24 VDC, drive powered
3
c) Other than Table "Nine Cell, GenIV,
Core Hardwired I/O Assignments"
Digital Outputs 16 Dry N.O. Contacts, rated
250 VAC @ 6A
a) Dry N.C. Contacts
b) Other than Table "Nine Cell, GenIV,
Core Hardwired I/O Assignments"
Analog Inputs 3 4-20 mADC a) (2) 0-10 VDC inputs
b) Other than Table "Nine Cell, GenIV,
Core Hardwired I/O Assignments"
Analog Outputs 2 4-20 mADC a) Other than Table "Nine Cell, GenIV,
Core Hardwired I/O Assignments"
1. Drive Powered Digital Inputs
2. Subject to Custom Engineering Requirements
3. Requires Custom Engineering
Note
Network communications have provisions for I/O signalization as described in the
NXG
Control Manual A1A9001588
and
NXG Communications Manual A1A902399
. For GenIV
expansion, hardwired I/O must be treated as Custom engineering and requires the use of a
Transition cabinet due to the limited space available within the core drive.
Table 5- 14 Nine Cell, GenIV, Core Hardwired I/O Assignments
(Subject to Change. Always refer to the project "A" and "B" for I/O assignments)
Signal Type Signal Name Function
Digital Input IDI-0A Remote Inhibit
Digital Input IDI-1A Remote Start
Digital Input IDI-2A Remote Stop
Digital Input IDI-3A Remote Fault Reset
Digital Input IDI-0B SW1-Off
