ARCADIS Orbic Quick Guide
Product Overview
15
Moving the C-arm system
(1) Vertical travel (motorized)
Lift and lower C-arm
up to 40 cm
(2) Orbital movement
Change between a.p. and lateral position
➭ Starting from the a.p. position, C-arm
swivels by 95° in both directions, 190° in
total.
(3) Angulation
Rotate C-arm about support arm in verti-
cal plane
by up to 190° in both directions
(4) Horizontal travel
Move C-arm horizontally
up to 20 cm
➭ Ideal for fine adjustments directly at the
OR-table.
(5) Swivel
Swivel C-arm about unit column in hori-
zontal plane
by up to 10° in each direction
➭ Ideal for fine adjustments directly at the
OR-table.
