ARCADIS Orbic Quick Guide
Postprocessing
57
Measuring and annotations
In the Tools subtask card images can be mea-
sured and annotations can be added.
(1) Diaphragms
The subsequent simulation of diaphragms
improves the visualization of fine struc-
tures that are difficult to see in the image
(2) Magnifying glass
Individual areas of the loaded image are
shown enlarged
(3) Annotations
Entering annotations for image areas via
the keyboard
(4) Calibrating and measuring distances
(5) Angle measurement
The angle between two straight lines to
be drawn is indicated
