ARCADIS Orbic Quick Guide
3D option
81
3D display modes
From the MPR standard display you can
switch to the following display modes for the
scanned volume:
❏ MPR Thick
Images with adjustable slice thickness
❏ SSD (Shaded Surface Display)
Three-dimensional surface reconstruction
✧ First, click the segment for which you
want to change the output type.
Setting MPR Thick
✧ Using the left mouse button, click the
MPR button on the Ty p e subtask card (1).
➭ The display mode is changed.
✧ To set a different slice thickness, click the
MPR button (1) with the right mouse but-
ton.
✧ Enter the required slice thickness in the
dialog displayed and confirm with OK (2).
Setting SSD
✧ Click the SSD button on the Ty p e subtask
card (3).
➭ The SSD reconstruction is performed in
the selected reference segment (4).
