Siemens ARCADIS Orbic - Table of Contents

ARCADIS Orbic Quick Guide
4
Table of Contents
Basics
Input devices ........................................ 7
syngo user interface............................. 9
syngo control elements ......................11
Product Overview
C-arm system ..................................... 13
Monitor trolley .....................................17
Examination Procedure
Preparing the system ......................... 19
Patient registration ............................. 21
Preparation in the
Examination task card ........................ 23
Radiation release and dose display .... 25
High-contrast fluoroscopy
(Power Mode) .................................... 29
Image rotation and reversal ................ 31
Collimator setting ............................... 33
Changing the contrast ........................ 35
Saving images .................................... 37
Fluoro Loop/LSH (option) ................... 39
Ending the examination ..................... 39
Subtraction and Roadmap
Performing a subtraction scene ......... 41
Postprocessing a
subtraction scene............................... 43
Roadmap ............................................ 51
Postprocessing
Loading patient images into
the Viewing task card ......................... 53
Image display ..................................... 55
Measuring and annotations................ 57
Image manipulation............................ 61
