ARCADIS Orbic Quick Guide
Postprocessing
59
Calibrating and measuring distances
❏ Calibrating (1st step)
✧ Activate the calibration function by click-
ing the corresponding button (1).
➭ A green line appears in the image area
which can be lengthened, shortened and
positioned as desired with the mouse (2).
✧ Draw the line along a known distance (2).
➭ As soon as you release the mouse button,
a dialog box appears (3).
✧ Enter the known distance and confirm
with OK (3).
➭ The calibration is shown in the image
area. At the same time, a measuring scale
appears on the right edge of the image.
❏ Measuring distances (2nd step)
✧ Activate the Distance function by clicking
the corresponding button (4).
✧ Using the left mouse button, draw a line
along the required structure.
➭ As soon as you release the left mouse
button, the distance from the start to the
end point of this line is shown (5).
