ARCADIS Orbic Quick Guide
3D option
83
Changing the SSD threshold
If necessary, the preset threshold values for
the surface reconstruction can be changed
individually.
✧ Click the SSD button (1) with the right
mouse button.
➭ The display of the 3D card is reset for opti-
mizing the threshold values:
(2) Reference segments in MPR mode (areas
within threshold values highlighted)
(3) SSD Definition dialog
(4) Output segment with SSD display based
on current threshold values
✧ Change the threshold values with the
slider or enter new values in the input
fields.
✧ The click the High Quality button (5).
Setting the SSD light source
You can change the light source to achieve a
better display of the surface condition of ana-
tomical structures.
✧ Click the Light Source Definition - SSD
button (6).
✧ Select one of the presets or set the
required values with the sliders (7).
✧ Confirm with OK.
